.4. Safety Devices

Control and monitoring circuits ensure control and safety during malfunctions of the PA. These are on the
Control board and the Protection board. Control board is located behind the front panel. Protection board is
visible on the right hand side of PA, close to the input/output relay.
Protection board with Input circuits. Input splitter together with HW
protection is visible down on the board. Some of protection circuits are
installed on the Control board (behind the front panel), too.
