Top view on the power amplifier
Input board with output coax relay together with SWR
board is visible on the right upper side.
Left side shows the main RF part – two boards with
MOSFETs amplifiers, everyone for max. 1 kW of output
power.
Down are two axial fans on the left side, together with
display board and controller board.
On the right bottom side the PCB of small 12V DC power
supply is visible.
14
