Cypress Semiconductor CY3215-DK PSOC Quick Start Manual

CY3215-DK PS
1
Install Software
1. Insert the CY3215-DK CD into the CD
drive of your PC.
2. Install the kit contents, PSoC Designer,
and PSoC Programmer.
Note: You can also downlad the latest
software and documents from
http://www.cypress.com/go/CY3215-DK.
3
Use MiniEval to Program
1. Attach the backward compatibility
adapter to the ICE-Cube in the place
of the flex-pod.
2. Connect the RJ45 end of the ISSP
cable into the adapter.
®
C IN-CIRCUIT EMULATOR DEVELOPMENT KIT
O
QUICK START GUIDE
2
Use MiniEval to Evaluate
1. Attach the flex cable and pod to the
ICE-Cube (ICE base unit).
2. Plug the 28-pin feet to the pod and
connect the MiniEval board via the ZIF
socket.
3. Create a project in PSoC Designer and
start debugging.
4
Use MiniEval to Program
3. Insert the IC on the ZIF socket.
4. Connect the 5-pin connector of the ISSP
cable to the MiniEval.
5. Program the parts using PSoC
Programmer.
