CY3215-DK IN-CIRCUIT EMULATOR DEVELOPMENT KIT
1
Install Software
1. Install PSoC Designer from the CD-ROM
or download the latest version from
http://www.cypress.com/psoc.
3
Use MiniEval to Program
1. Attach the backward compatibility
adapter to the ICE-Cube in the place
of Flex-Pod.
2. Connect the RJ45 end of the ISSP
cable into the adapter.
QUICK START GUIDE
2
Use MiniEval to Evaluate
1. Attach the Flex cable and Pod to the
ICE-Cube.
2. Plug the 28-pin feet to the Pod and
connect MiniEval board via the ZIF
socket.
3. Create a project in PSoC Designer and
start debugging.
4
Use MiniEval to Program
3. Connect the 5-pin connector of the ISSP
cable to the MiniEval.
4. Program the parts using PSoC
Programmer.
