FA01624-EN
PLX A
EN English
USER MANUAL

Advertisement

Table of Contents
loading

Related Manuals for CAME PLX A

Summary of Contents for CAME PLX A

  • Page 1 FA01624-EN PLX A EN English USER MANUAL...

  • Page 2: General Precautions

    The manufacture date is provided in the production batch printed on the product label. If necessary, contact us at https://www.came.com/global/en/contact-us. The general conditions of sale are given in the offi cial CAME price lists. Function of buttons Press this button to activate and deactivate communication.
  • Page 3 Press this button to adjust the ringtone volume: LOW, MEDIUM, HIGH, OFF. LED key red On: the volume is off . ☞ Press the button during a conversation to adjust the audio volume. Auxiliary 2 / Porter call. This signals a request to be called back by the porter. This button sends a DOOR RELEASE or GATE RELEASE command.

  • Page 4: Standard Functions

    The function of this button depends on the confi guration set during installation. If the button is confi gured as an INTERCOM, it will temporarily enable the SECOND FUNCTION, allowing INTERCOM calls 4 to 6 to be activated. ☞ When the second function is active, the white LEDs on the buttons 1,2,3,4 will fl...
  • Page 5 Intercommunication Press the button to select the desired internal receiver. The calling receiver will sound to indicate that the line is free. The called receiver will ring with the chosen ringtone. Press this button on the called receiver to activate audio communication. ☞ During a conversation between internal receivers, a call from an entry panel is signalled on the internal receivers by a beep that repeats every 5 seconds.

  • Page 6: Auxiliary Controls

    Auxiliary controls Press the AUX button to activate the desired auxiliary command. Example switching on a light or opening the gate. ☞ Accessory devices may be required for these commands to work properly. Call forwarding With a call active, select the internal receiver to which you want to transfer the call.
  • Page 7 Int.2 Int. 1 To activate audio communication between two internal receivers, press this button on the called receiver. The entry panel will be put on hold. To allow internal receiver 2 to communicate with the entry panel, press this button on internal receiver 1.
  • Page 8 Porter functions These functions are only available if the system has a porter desk. Call notifi cation from the porter CONTACT ME When this button LED lights up, this means the porter would like to be called back. ☞  The LED turns off when communication with the porter starts.
  • Page 9 Sending a panic signal to the porter Press and hold this button for 2 seconds to send a PANIC signal to the porter. The white LED indicates that the signal has been received by the porter. PANIC! Alarm signal If an alarm contact connected to the relevant receiver entrance is activated, a signal is sent to the porter and an intermittent acoustic signal sounds on the...
  • Page 10 Open-gate function/status Press and hold the button for a prolonged period to send an open/close command to an operator. The LED indicates the status of the operator. ☞  The system must be correctly set up and confi gured. ☞  The function must be activated on the receiver when the call is being associated during system programming.
  • Page 11 Configuring melodies ☞ Perform each of the following confi guration steps, in succession: Entering confi guration mode Press and hold the button for 3 seconds. A short buzzing sound and a red fl ashing LED confi rm that you have entered confi...
  • Page 12 Press this button to select the melody and exit confi guration. Press this button to select the melody and continue confi guration. ☞  You will hear two short beeps to confi rm that you have entered landing-call confi guration mode Confi...
  • Page 13 Press this button to select the melody and exit confi guration. Press this button to select the melody and continue confi guration. ☞  You will hear three short beeps to confi rm that you have entered confi guration mode for the number of rings per call.

  • Page 14: Technical Data

    Press this button to exit confi guration. Technical data Type PLX A Power supply from BUS (V DC) 15 to 20 Consumption in stand-by mode (mA) <1 Maximum consumption (mA) Single LED consumption (mA) Storage temperature (°C)* -25 to +70 Operating temperature (°C)

  • Page 15: Cleaning The Device

    Legislative references This product complies with the applicable standards in force at the time of manufacturing. FCC - This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference / (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 16 CAME S.p.A. Via Martiri Della Libertà, 15 31030 Dosson di Casier - Treviso - Italy tel. (+39) 0422 4940 - fax. (+39) 0422 4941 info@came.com - www.came.com...
