Assembly
Handle
The compressor handle is to be assembled as follows:
Fig. 2
1 Get the two threaded pins from the accessory bag and
put them into the threaded holes in the handle tubes.
2 Push the two handle ends into the fixing holes.
3 Tighten the screws to fix the handle in place.
Wheels, Fig. 3
1 To secure the wheels (12), first place a disc with the
wheel bolts through the wheel. Then, add a disc and
a hex-nut on the inside of the wheel. Now tighten the
nut by hand to the greatest extent that will allow the
wheel to still rotate.
2 Slide the wheel through the clip under the tank.
3 Then fasten it with a disc, a safety glass, and a nut and
tighten them together.
4 Repeat this process for the second wheel.
Rubber foot, Fig. 4
Fasten the rubber foot to the flap at the lower front part of
the tank using the screw, washer and nut provided.
Oil, Fig. 5
Warning: It is absolutely necessary to check the oil fill level
before the first use!
Operating the machine without oil will cause irreparable
damage and render the warranty invalid.
1 Remove the plastic oil inlet plug with dip stick (14)
from the upper part of the crank case in the compres-
sor housing.
2 Check the oil fill level by completely screwing in the
dip stick. The oil must cover the marking.
3 Re-insert the oil dip stick (14) and tighten it.
