- Page 1 Model Document Vallox TSK Multi 50 MC D2585 Vallox TSK Multi 80 MC Valid from 07.03.2022 Types 3603 Updated B3602 20.06.2022 Manual Low-energy ventilation unit with heat recovery...
- Page 2 (optional) (ordered separately) Vallox ProControl panel (ordered separately) Vallox Delico PTD EC control hood, Vallox X-Line PTXP MC control hood, or Vallox X-Line PTXPA MC control hood (ordered separately) WARNING! The unit is not intended for use by children under 8 or by persons with reduced sensory, physical or mental capabilities, or whose lack of knowledge and experience do not ensure safe operation of the unit. ...
-
Page 3: Fan Speed Adjustment
FAN SPEED ADJUSTMENT The fan speed of the Vallox ventilation unit is adjusted using a four-step control (optional). The available speed options of the control switch are 1, 2, 3, and 4: Away mode. The ventilation efficiency can be temporarily reduced when the apartment is unoccupied. -
Page 4: Maintenance Reminder
The maintenance reminder will be set off automatically when the door of the ventilation unit is opened or the power is turned off. The maintenance reminder can also be set off manually. Vallox Simple Control panel, and Vallox X-Line Vallox Delico PTD EC control hood: PTXP MC and PTXPA MC control hoods, VAK •... -
Page 5: Troubleshooting Table
The safety switch (S) automatically turns off the power In the L model, the parts are mirrored when the door of the Vallox TSK Multi 50/80 MC ventilation unit is opened. Always disconnect the power plug before starting the Vallox TSK Multi 50/80 MC ventilation unit maintenance. -
Page 6: Heat Recovery Cell
HEAT RECOVERY CELL Check that the heat recovery cell (D) is clean roughly once a year when the filters are being replaced. Clean by washing as required. • Pull the coarse filters including the frames out of the unit (A and C). Also remove the fine filter, if any (C). •... - Page 7 5,. Turn the fan 90° and 5. Tilt the fan tilt it forward to pull it forward to pull it out of the unit. out of the unit. Install the fan beds in a reverse order. © Vallox Oy - All rights reserved...
- Page 8 VALLOX TSK MULTI 50 MC Air flow Supply air TECHNICAL SPECIFICATIONS measurement Product title Product number Extract air Vallox TSK Multi 50 MC R 3462600 points Vallox TSK Multi 50 MC L 3462700 Air volumes Supply air 47 dm3/s, 100 Pa...
- Page 9 Total height with an elbow 264 mm 3. Outdoor air to the unit Space required Space required Total height with the Vallox Silent Klick for installation 47 mm for installation 70 mm 4. Supply air to the apartment water seal is 279 mm...
- Page 10 VALLOX TSK MULTI 80 MC Air flow Supply air TECHNICAL SPECIFICATIONS measurement Extract air Product title Product number Vallox TSK Multi 80 MC R 3478000 points Vallox TSK Multi 80 MC L 3478100 Air volumes Supply air 85 dm3/s, 100 Pa...
- Page 11 3. Outdoor air to the unit Space required Space required for installation 47 mm for installation 70 mm Total height with the Vallox Silent Klick 4. Supply air to the apartment Elbow Water seal water seal is 336 mm sound values...
-
Page 12: Electrical Connection
ELECTRICAL CONNECTION... -
Page 13: Electrical Connections
– contact closed from the female terminal of the control connector damper closed – contact open EXTERNAL ELECTRICAL CONNECTION with the Vallox Simple Control control panel / Vallox PTXP MC, Vallox PTXPA MC cooker hood Control signal S Internal connection 11.2 Vdc / +... - Page 14 EXTERNAL ELECTRICAL CONNECTION with Vallox ProControl control panel Wiring between the control panel and the ventilation unit, NOMAK 2x2x0.5+0.5 Ventilation unit cable Control panel connector leave disconnected S/DI2 Cable types specified in the drawing are indicative The phase of 24 VAC feed is connected...
-
Page 15: Installation Site
INSTALLATION SITE Mounting The Vallox TSK Multi 50/80 MC is normally installed on the Vallox TSK Multi 50/80 MC must be installed in a location ceiling using the four mounting hooks delivered with the unit. where the temperature remains above +10°C. When the... -
Page 16: Exploded View And Parts List
(Vallox TSK Multi 80 MC) Finger screw for the door ................990698 15 Filter stand (Coarse, supply) 500mm (Vallox TSK Multi 50 MC) ..3356400 Heat recovery cell (Vallox TSK Multi 50 MC)..........933120 15 Filter stand (Coarse, supply) 580mm (Vallox TSK Multi 80 MC) ..3352700 Heat recovery cell (Vallox TSK Multi 80 MC) ..........933130...
