Table 20 - Service Mode Features Continued
Service Service Mode
Mode
Replace Cutter
Printer
Carriage
Purge
Clear
Exchange
Detail-Cnt
Ink-Use1
Ink-Use2
Ink-Exc
Counter
Media X (X: 1 To 7)
Media Other
Mediasize1 Roll
Mediasize2 Roll
Mediasize1 Cut
Mediasize2 Cut
Head Dot Cnt. 1
Head Dot Cnt. 2
Parts Cnt.
Pth
Rtc
Pv Auto Judge
Setting Network
E-Rds
Head Dot INF
Tsc
Warnig
Error
Jam
Adjust
W-Ink
Carriage
Purge
Ink-Use Cnt
Initialize W-Ink-Chg Cnt
Head-Chg Cnt
Hdd Box Pass.
Parts-Chg Cnt
Parts Counter
User Setteing
Ca-Key
Erds-Dat
Job Log
imagePROGRAF iPF850/iPF840/iPF830 Service Guide
Feature
This mode is for replacing the cutter.
Counters related to product life
Counters related to carriage unit
Counters related to purge unit
Counters related to counter initialization
Counters related to parts replacement
Other counters
Counters related to ink consumption
Counters related to ink consumption
Counters related to ink tank replacement
Counters related to media. One to seven media types are displayed
individually in order with large cumulative print area.
Counters related to media. Displays the total amount of cumulative
print area of the other media type than the above-mentioned
Counters related to roll media printing
Counters related to cut sheet printing
Counter related to dot count
Counter related to consumable parts
Turn on or off the head pulse rank control function.
Set real time clock after replacing the lithium battery on the main
controller PCB.
Sets ink saver mode.
Make network settings.
Set Remote diagnostic System Settings
Set ON/OFF to display a message regarding the total ejection dot
count discharged from the print head.
Make indication settings about TSC.
Initialize or clears the histories, settings or counter values, and other
parameters.
