Overview; Specifications - Altronix VertiLine24C Series Installation Manual

Altronix VertiLine CCTV Rack Mount Power Supplies provide 24 power outputs in a space saving 1U EIA 19" rack
mount chassis which may be rack, wall or shelf mounted. The units feature individually selectable 24VAC and/or
28VAC power outputs with surge suppression. VertiLine CCTV Rack Mount Power Supplies are also available in
eight (8) and sixteen (16) output models with various power ratings.
Input:
• 115VAC, 60Hz input.
Output:
• Twenty-four (24) individually selectable 24VAC
or 28VAC power outputs with OFF position.
• Twenty-four (24) external blade fuse or
PTC protected outputs.
• Surge suppression.
Features:
• Twenty-four (24) power LED indicators.
• Removable terminal blocks with
locking screw flange.
Twenty-four (24) Output Rack Mount Configuration
Altronix
Model
Number
24VAC or
VertiLine24C
28VAC
24VAC or
VertiLine24CD
28VAC
24VAC or
VertiLine246C
28VAC
24VAC or
VertiLine246CD
28VAC
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or mois-
ture. This installation should be made by qualified service personnel and should conform to
the National Electrical Code and all local codes.
- 2 -

Overview:

Specifications:

Reference Chart:
10A 24 Fused
10A 24 – PTC
14A 24 Fused
14A 24 – PTC
Features (cont'd):
• Illuminated master power disconnect
circuit breaker with manual reset.
• IEC 320 - 3-wire grounded line cord (detachable).
Mechanical:
• Units can be rack, wall or shelf mounted.
• Modular 1U standard EIA 19" rack mount chassis
• Enclosure Dimensions (H x W x D approx.):
1.625" x 19.125" x 8.5"
(41.3mm x 486mm x 216mm).
– 3A 3A
10A 3A
2.5A –
– 3A 3A
15A 4A
2.5A –
UL Listed for
Commercial
CCTV Equipment
(UL 2044).
cUL Listed - CSA
Standard
C22.2 No.1-04,
Audio, Video and
Similar Equipment.
VertiLine24C Series Installation Guide
