VertiLine24C Series
CCTV Rack Mount Power Supplies
Models Include:
VertiLine24C
- 24VAC or 28VAC @ 10A
- Twenty-four (24) fuse protected outputs
VertiLine246C
- 24VAC or 28VAC @ 14A
- Twenty-four (24) fuse protected outputs
Installation Guide
Rev. 031808
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
VertiLine24CD
- 24VAC or 28VAC @ 10A
- Twenty-four (24) PTC protected outputs
VertiLine246CD
- 24VAC or 28VAC @ 14A
- Twenty-four (24) PTC protected outputs
More than just power.
TM
Advertisement
Table of Contents
Related Manuals for Altronix VertiLine24C Series
Summary of Contents for Altronix VertiLine24C Series
- Page 1 VertiLine24C Series CCTV Rack Mount Power Supplies Models Include: VertiLine24C VertiLine24CD - 24VAC or 28VAC @ 10A - 24VAC or 28VAC @ 10A - Twenty-four (24) fuse protected outputs - Twenty-four (24) PTC protected outputs VertiLine246C VertiLine246CD - 24VAC or 28VAC @ 14A...
- Page 2 Overview: Altronix VertiLine CCTV Rack Mount Power Supplies provide 24 power outputs in a space saving 1U EIA 19” rack mount chassis which may be rack, wall or shelf mounted. The units feature individually selectable 24VAC and/or 28VAC power outputs with surge suppression. VertiLine CCTV Rack Mount Power Supplies are also available in eight (8) and sixteen (16) output models with various power ratings.
- Page 3 *Note: Replace fuses with same type and rating: Output fuses are rated @ 3A for all models. Automotive Main fuse ratings: Blade Fuse 10A for VertiLine24C and VertiLine24CD. 15A for VertiLine246C and VertiLine246CD. VertiLine24C Series Installation Guide - 3 -...
- Page 4 Fig. 1 1a - LED(s) 1-24: Power LED indicators. 1b - Output voltage switches: Selects 24VAC or 28VAC or OFF for each output. VertiLine24C, VertiLine24CD, VertiLine246C or VertiLine246CD (front) RESET 28VAC 28VAC 28VAC 28VAC 24VAC 24VAC 24VAC 24VAC VertiLine24C or VertiLine246C (rear) Main Fuse Main Fuse 13-24...
- Page 5 Typical Hookup: Fig. 2 RESET 28VAC 28VAC 28VAC 28VAC 24VAC 24VAC 24VAC 24VAC Main Fuse Main Fuse 13-24 1-12 AC POWER...
- Page 6 Circuit breaker tripped - Switch not illuminated. Power LEDs on faceplate are not illuminated. Outputs not powered. To reset circuit breaker set power switch to the ON (RESET) position (Fig. 3, pg. 6) . - 6 - VertiLine24C Series Installation Guide...
- Page 7 (Fig. 6) . Place unit in desired location. Fig. 6 Two (2) mounting brackets Left Side Six (6) flat head screws for mounting brackets. Four (4) rubber pads. Rubber Pad VertiLine24C Series Installation Guide - 7 -...
- Page 8 Notes: Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty MEMBER IIVertiLine24C Series K04U - 8 - VertiLine24C Series Installation Guide...
