VertiLine3DV Series
Rack Mount Power Supplies
Models Include:
VertiLine3DV
- 12VDC @ 8A
- Eight (8) PTC protected outputs
VertiLine6DV
- 24VDC @ 8A
- Eight (8) PTC protected outputs
Installation Guide
Rev. 090111
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
More than just power.
TM
Advertisement
Table of Contents
Related Manuals for Altronix VertiLine3DV Series
Summary of Contents for Altronix VertiLine3DV Series
- Page 1 VertiLine3DV Series Rack Mount Power Supplies Models Include: VertiLine3DV - 12VDC @ 8A - Eight (8) PTC protected outputs VertiLine6DV - 24VDC @ 8A - Eight (8) PTC protected outputs Installation Guide More than just power. Rev. 090111 Installing Company: _______________ Service Rep. Name: __________________________________...
-
Page 2: Specifications
Overview: Altronix VertiLine Rack Mount Power Supplies provide eight (8) filtered and electronically regulated power outputs in a space saving 1U EIA 19” rack mount chassis. The units are available with either 12VDC or 24VDC power outputs. VertiLine Rack Mount Power Supplies are also available in sixteen (16) outputs. -
Page 3: Installation Instructions
Installation Instructions: 1. Attach mounting brackets to VertiLine unit for desired rack or wall mount installation (Figs. 4-5, pg. 7). Affix rubber pads to VertiLine for shelf installation (Fig. 6, pg. 7). 2. Secure the unit into rack, mount unit to wall or place unit on a shelf as desired (unit should be spaced at least 3”... - Page 4 - 4 - VertiLine3DV / VertiLine6DV Installation Guide...
- Page 5 VertiLine3DV / VertiLine6DV Installation Guide - 5 -...
- Page 6 The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user to the presence of an insulated DANGEROUS VOLTAGE within the product’s enclosure that may be of sufficient magnitude to constitute an electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
-
Page 7: Rack Mount Installation
Mounting Options: Rack Mount Installation Remove factory installed screws from both sides of the rack chassis (Fig. 4a). Install mounting brackets (A) on the left and right side of rack chassis using the two (2) flat head screws (B) (included) (Fig. 4b). Place unit into desired EIA 19”... - Page 8 Notes: Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIVertiLine3DV / VertiLine6DV G20U MEMBER - 8 -...
