VertiLine 33DV/63DV Series
Rack Mount Power Supplies
Models Include:
VertiLine33DV
- 12VDC @ 8A
- Sixteen (16) PTC protected outputs
VertiLine33TDV
- 12VDC @ 16A
- Sixteen (16) PTC protected outputs
Installation Guide
Rev. 090810
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
VertiLine63DV
- 24VDC @ 8A
- Sixteen (16) PTC protected outputs
VertiLine63TDV
- 24VDC @ 16A
- Sixteen (16) PTC protected outputs
More than just power.
TM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Altronix VertiLine 33DV Series
Summary of Contents for Altronix VertiLine 33DV Series
- Page 1 VertiLine 33DV/63DV Series Rack Mount Power Supplies Models Include: VertiLine33DV VertiLine63DV - 12VDC @ 8A - 24VDC @ 8A - Sixteen (16) PTC protected outputs - Sixteen (16) PTC protected outputs VertiLine33TDV VertiLine63TDV - 12VDC @ 16A - 24VDC @ 16A - Sixteen (16) PTC protected outputs - Sixteen (16) PTC protected outputs Installation Guide...
-
Page 2: Specifications
Overview: Altronix VertiLine Rack Mount Power Supplies provide sixteen (16) filtered and electronically regulated power outputs in a space saving 1U EIA 19” rack mount chassis. The units are available with either 12VDC or 24VDC power outputs. VertiLine Rack Mount Power Supplies are also available with eight (8) outputs. -
Page 3: Installation Instructions
Installation Instructions: 1. Attach mounting brackets to VertiLine unit for rack or wall mount installation (Figs. 4-5, pg. 7). Affix rubber pads to VertiLine for shelf installation (Fig. 6, pg. 7). 2. Secure the unit into rack, mount unit to a wall or place unit on a shelf as desired (unit should be spaced at least 3”... - Page 4 - 4 - VertiLine33DV / 63DV Series Installation Guide...
- Page 5 VertiLine33DV / 63DV Series Installation Guide - 5 -...
- Page 6 The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of an insulated DANGEROUS VOLTAGE within the product’s enclosure that may be of sufficient magnitude to constitute an electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of impor- tant operating and maintenance (servicing) instructions in the literature accompanying the appliance.
-
Page 7: Rack Mount Installation
Mounting Options: Rack Mount Installation Remove factory installed screws from both sides of the rack chassis (Fig. 4a). Install mounting brackets (A) on the left and right side of rack chassis using the two (2) flat head screws (B) (included) (Fig. 4b). Place unit into desired EIA 19”... - Page 8 Notes: Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIVertiLine33DV/63DV Series K04U MEMBER - 8 - VertiLine33DV / 63DV Series Installation Guide...
