VertiLine24 Series
CCTV Rack Mount Power Supplies
Models Include:
VertiLine24
- 24VAC or 28VAC @ 10A
- Twenty-four (24) fuse protected outputs
VertiLine246
- 24VAC or 28VAC @ 14A
- Twenty-four (24) fuse protected outputs
Installation Guide
Rev. 031808
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
VertiLine24D
- 24VAC or 28VAC @ 10A
- Twenty-four (24) PTC protected outputs
VertiLine246D
- 24VAC or 28VAC @ 14A
- Twenty-four (24) PTC protected outputs
More than just power.
TM
Advertisement
Table of Contents
Related Manuals for Altronix VertiLine24 Series
Summary of Contents for Altronix VertiLine24 Series
- Page 1 VertiLine24 Series CCTV Rack Mount Power Supplies Models Include: VertiLine24 VertiLine24D - 24VAC or 28VAC @ 10A - 24VAC or 28VAC @ 10A - Twenty-four (24) fuse protected outputs - Twenty-four (24) PTC protected outputs VertiLine246 VertiLine246D - 24VAC or 28VAC @ 14A...
-
Page 2: Specifications
Overview: Altronix VertiLine CCTV Rack Mount Power Supplies provide 24 power outputs in a space saving 1U EIA 19” rack mount chassis which may be rack, wall or shelf mounted. The units feature individually selectable 24VAC and/or 28VAC power outputs with surge suppression. VertiLine CCTV Rack Mount Power Supplies are also available in eight (8) and sixteen (16) output models with various power ratings. -
Page 3: Installation Instructions
Installation Instructions: 1. Set the input voltage selector switch located on the left side of the VertiLine unit (facing front panel) for 115VAC or 230VAC operation (Fig. 1c, pg. 4). 2. Attach mounting brackets to VertiLine unit for rack or wall mount installation (Figs. 4-5, pg. 7). Affix rubber pads to VertiLine for shelf installation (Fig. - Page 4 - 4 - VertilLine24 Series Installation Guide...
- Page 5 VertilLine24 Series Installation Guide - 5 -...
-
Page 6: Top And Bottom
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of an insulated DANGEROUS VOLTAGE within the product’s enclosure that may be of sufficient magnitude to constitute an electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of impor- tant operating and maintenance (servicing) instructions in the literature accompanying the appliance. -
Page 7: Rack Mount Installation
Mounting Options: Rack Mount Installation Remove factory installed screws from both sides of the rack chassis (Fig. 4a). Install mounting brackets (A) on the left and right side of rack chassis using the two (2) flat head screws (B) (included) (Fig. 4b). Place unit into desired EIA 19”... - Page 8 Notes: Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIVertiLine24 Series K04U MEMBER - 8 - VertilLine24 Series Installation Guide...
