PARTS LIST
ITEM QTY REFERENCE
Required Circuit Components
1 6 C1, C3, C5, C11, C13, C17
2 2 C4, C15
3 2 C6, C14
4 1 R2
5 1 R5
6 1 R6
7 1 R9
8 1 R13
9 2 U1, U2
Additional Demo Board Circuit Components
1 4 C2, C7, C10, C12
2 2 R1, R8
3 1 R3
4 1 R4
5 2 R7, R14
6 1 R10
7 1 R11
8 1 R12
Hardware
1 12 E1-E4, E7, E10, E12-E15, E18, E21 TEST POINT, TURRET, 0.094" MTG. HOLE,
2 10 E5, E6, E8, E9, E11, E16, E17, E19,
E20, E22
3 2 JP1, JP4
4 2 JP2, JP3
5 4 MP1-MP4
6 4 XJP1, XJP2, XJP4, XJP5
DEMO MANUAL DC2585A
PART DESCRIPTION
CAP ., 1μF, X7R, 100V, 10%, 1206
CAP ., 10μF, X7S, 100V, 10%, 1210
CAP ., 4.7μF, X5R, 6.3V, 20%, 0402
RES., 698k, 1%, 1/16W, 0402, AEC-Q200
RES., 10MΩ, 5%, 1/16W, 0402
RES., 49.9k, 1%, 1/16W, 0402, AEC-Q200
RES., 499k, 1%, 1/16W, 0402, AEC-Q200
RES., 100k, 1%, 1/10W, 0402, AEC-Q200
IC, HIGH VOLTAGE BOOST CHARGE PUMP
CAP ., 10μF, X7S, 100V, 10%, 1210
RES., 100k, 5%, 1/16W, 0402
RES., 1.15MΩ, 1%, 1/16W, 0402, AEC-Q200
RES., 2.05MΩ, 1%, 1/16W, 0402
RES., 510k, 5%, 1/16W, 0402
RES., 1MΩ, 1%, 1/16W, 0402, AEC-Q200
RES., 1.5MΩ, 1%, 1/16W, 0402, AEC-Q200
RES., 10MΩ, 5%, 1/16W, 0402
PCB 0.062" THK
TEST POINT, TURRET, 0.064" MTG. HOLE,
PCB 0.062" THK
CONN., HDR., MALE, 2×3, 2mm, VERT,
STR, THT
CONN., HDR, MALE, 1×3, 2mm, VERT, STR, THT WURTH ELEKTRONIK, 62000311121
STANDOFF , NYLON, SNAP-ON, 0.25" (6.4mm)
CONN., SHUNT, FEMALE, 2 POS, 2mm
MANUFACTURER/PART NUMBER
AVX, 12061C105KAT2A
MURATA, GRM32EC72A106KE05L
MURATA, GRM155R60J475ME87D
VISHAY, CRCW0402698KFKED
VISHAY, CRCW040210M0JNED
VISHAY, CRCW040249K9FKED
VISHAY, CRCW0402499KFKED
PANASONIC, ERJ2RKF1003X
ANALOG DEVICES, LTC3290EMSE#PBF
MURATA, GRM32EC72A106KE05L
YAGEO, RC0402JR-07100KL
VISHAY, CRCW04021M15FKED
VISHAY, CRCW04022M05FKED
VISHAY, CRCW0402510KJNED
VISHAY, CRCW04021M00FKED
VISHAY, CRCW04021M50FKED
VISHAY, CRCW040210M0JNED
MILL-MAX, 2501-2-00-80-00-00-07-0
MILL-MAX, 2308-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000621121
KEYSTONE, 8831
WURTH ELEKTRONIK, 60800213421
