Operating Instructions

Control Panel Features
Wireless button(On some models)
Used to initiate the wireless connection
mode. For the first time to use wireless
function, press the wireless button for 3
seconds to initiate the wireless connection
mode. The LED DISPLAY shows 'AP' to
indicate you can set wireless connection.
If connection(router) is successful within
8 minutes, the unit will exit wireless
connection mode automatically and the
wireless indicator illuminates. If
connection is failure within 8 minutes, the
unit exits wireless connection mode
automatically. After Wireless connection
is successful, for some models you can
press Wireless and DOWN (-) buttons at
the same time for 0.5 seconds to turn off
Wireless function and the LED DISPLAY
shows 'OF' for 3 seconds, press Wireless
button to turn on Wireless function and
the LED DISPLAY shows 'ON' for 3
seconds.
NOTE: When you restart the wireless
function, it may take a period of time to
connect to the network automatically.
Swing Button
(Applicable to the models with auto swing
feature only)
Used to initiate the Auto Swing feature.
When the operation is ON, pressing the
SWING button can stop the louver at the
desired angle.
Timer button
Used to initiate the AUTO ON start time
and AUTO OFF stop time program,
in conjunction with the + & - buttons.
The timer on or off light will illuminate
depending on the selected setting.
Mode button
Selects the desired operating mode.
Each time you press the button, a mode
is selected in a sequence that goes
from AUTO, COOL, DRY FAN and HEAT.
The mode light illuminates and indicates
the selected mode. (cooling only models
excluded)
Up (+) and Down (-) buttons
Used to adjust (increasing/decreasing)
temperature settings in 1°C/1°F
increments in a range of 17°C/62°F to 30°
C/86°F or the TIMER setting in a range of
0 ~ 24hrs.
