- Page 1 Installation and operation manual Fan coil units FWF02D FWF03D Installation and operation manual FWF04D English Fan coil units FWF05D...
- Page 2 2P491002-9J...
- Page 3 4P702067-6C...
-
Page 4: Table Of Contents
▪ A subset of the latest technical data is available on the regional Daikin website (publicly accessible). For the user ▪ The full set of latest technical data is available on the Daikin 9 User safety instructions Business Portal (authentication required). -
Page 5: General
Disconnect the power supply for more Make sure installation, servicing, maintenance and repair than 10 minutes, and measure the comply with instructions from Daikin and with applicable legislation and are executed ONLY by authorised persons. voltage at the terminals of main circuit... -
Page 6: For The Installer
3 About the box WARNING CAUTION ▪ Do NOT use locally purchased electrical parts inside For walls containing a metal frame or a metal board, use a the product. wall embedded pipe and wall cover in the feed-through hole to prevent possible heat, electrical shock, or fire. ▪... -
Page 7: About The Units And Options
4 About the units and options Select an installation site where the following conditions are fulfilled About the units and options and that meets your customer approval. ▪ The space around the unit is adequate for maintenance and Identification servicing. The space around the unit allows sufficient air circulation and air distribution. -
Page 8: Mounting The Unit
5 Unit installation 5.2.2 To create ceiling opening Mounting the unit Use the paper pattern (upper part of the packing) (a) to create ceiling 5.2.1 To install the suspension bolts opening according to the outlines specified on the paper pattern. Attach paper pattern to the unit using the four screws (d) from the Use the pattern to determine the suspension bolt positions (upper accessory set and create the opening by referencing the ceiling... -
Page 9: Water Piping Installation
5 Unit installation Adjust the distance between the panels in the vertical direction as follows: Vertical distance for ceiling material Ceiling board Panel type BYFQ60B (Standard panel) 25 mm BYFQ60C (Design panel) 34 mm To create an opening in an existing monolithic ceiling board NOTICE It is necessary to provide a service space in the ceiling... -
Page 10: Connecting Water Piping
5 Unit installation ▪ Provide drain taps at all low points of the system to permit complete draining of the circuit during maintenance or service to the unit. ▪ Provide air purge valves at all high points of the system. The valves shall be located at points which are easily accessible for servicing. -
Page 11: Drain Piping Installation
5 Unit installation NOTICE Air in the water circuit can cause malfunctioning. During filling, it may not be possible to remove all the air from the circuit. Remaining air will be removed through the automatic air purge valves during the initial operating hours of the system. -
Page 12: Optional Equipment Installation
Degradation and damage of plastic parts. NOTICE In the case of using remote controller other than Daikin remote controllers, it should have the following features: ▪ Power supply 1 Ph, 230 V, 50 Hz. If a controller with a different power supply rating is used, the power supply can NOT be common with the unit. - Page 13 Silicone glass tube (in decorative panel accessory set) Tie wrap (in decorative panel accessory set) To install the on-off valve kits NOTICE The PCB connection of the valves is only required when Daikin ON/OFF valve (EKWV2V3W5A/ EKWV3V3W5A) is used. 2 Actuators (d)
- Page 14 5 Unit installation 3-way on off valve kit 4 The actuator surface (f) and the end of cable (g) are colour- coded to prevent switching the cables of the heating and cooling valves. 3 Valve insulations (e) and tie wraps (m) 2-way on off valve kit 5 Tie wraps (h).
-
Page 15: Electrical Installation
6 Electrical installation Preparing electrical wiring WARNING All field wiring and components MUST be installed by a licensed electrician and MUST comply with the applicable legislation. DANGER: RISK OF ELECTROCUTION WARNING A main switch or other means for disconnection, having a contact separation in all poles, MUST be incorporated in the fixed wiring in accordance with the applicable legislation. -
Page 16: Connecting The Electrical Wiring
Must comply with applicable legislation leakage circuit breaker Mentioned current is only for Daikin valves. Connecting the electrical wiring DANGER: RISK OF ELECTROCUTION 2 Cable clamps (a) and protection rubber (b). First connect the 0-10 V DC fan modulation cable to the X3M terminal. -
Page 17: Configuration
7 Configuration 3 Connect the AC heating and signal cables from the controller to the X2M terminal. 6 Cable clamps (c). 4 Connect the power supply cables (L, N, Earth) to the lower part of the X1M terminal as shown in the figure. Configuration Decorative panel setting Make the following field settings so that they correspond with the... -
Page 18: Commissioning
8 Commissioning NOTICE Make sure that the dip switch setting is correct according to panel type, otherwise panel will not work properly. Setting: Air flow direction and design panel NOTICE 35° If the flaps are required to open and close automatically, 36°... -
Page 19: Instructions For Safe Operation
10 About the system Instructions for safe operation WARNING Do NOT place a flammable spray CAUTION bottle near the air conditioner and do Do NOT insert fingers, rods or other NOT use sprays near the unit. Doing objects into the air inlet or outlet. When so may result in a fire. -
Page 20: Operation
12 Operation This operation manual offers a non-exhaustive overview of the main Maintenance and service functions of the system. For more information about the user interface, see the operation 14.1 Maintenance safety precautions manual of the installed user interface. DANGER: RISK OF BURNING/SCALDING Operation DANGER: RISK OF ELECTROCUTION 12.1... -
Page 21: Cleaning The Air Filter, Suction Grille, Air Outlet And Outside Panels
14 Maintenance and service Design panel: CAUTION Before accessing terminal devices, make sure to interrupt all power supply. NOTICE When cleaning the heat exchanger, make sure to remove the switch box, fan motor, drain pump and float switch. Water or detergent might deteriorate the insulation of electronic components and result in burnout of these components. -
Page 22: After A Long Stop Period
15 Troubleshooting 2 Remove the suction grille. access to a permanent stock of essential components in order to keep your unit in operation as long as possible. Contact your dealer Standard panel: for more information. When asking your dealer for an intervention, always state: ▪... -
Page 23: Relocation
16 Disposal If the system does NOT operate properly except for the above After installation, the installer is obliged to verify correct operation. In mentioned cases and none of the above mentioned malfunctions is case something is wrong with the unit and it does not operate, evident, investigate the system in accordance with the following contact your local dealer. -
Page 24: Technical Data
+ metal + plastic foam Technical data A subset of the latest technical data is available on the regional Daikin website (publicly accessible). The full set of latest technical data is available on the Daikin Business Portal (authentication required). 17.1... -
Page 25: Dimensions
17 Technical data Yellow Status lamp Network lamp Legend for wiring diagrams: A1/102 0-10 V DC fan modulation Indoor unit: CA/COM Common Main PCB O6/VH Heating signal Electronic board (FWECSAP) 05/VC Cooling signal Electronic control (FWECSAC) Phase Advanced plus remote controller Neutral (FWEC3A) Protective earth... - Page 26 17 Technical data 641.5 62.5 65.5 Side views with design panel (mm) Installation and operation manual FWF02~05D Fan coil units 3P443944-9T – 2023.01...
- Page 27 18 Information requirements for ecodesign FWF02~05D Installation and operation manual Fan coil units 3P443944-9T – 2023.01...
- Page 28 DAIKIN ISITMA VE SOĞUTMA SİSTEMLERİ SAN.TİC. A.Ş. Gülsuyu Mahallesi, Fevzi Çakmak Caddesi, Burçak Sokak, No:20, 34848 Maltepe İSTANBUL / TÜRKİYE Tel: 0216 453 27 00 Faks: 0216 671 06 00 Çağrı Merkezi: 444 999 0 Web: www.daikin.com.tr 3P443944-9T 2023.01 Verantwortung für Energie und Umwelt...
