7 1/2-to 12 1/2-ton three-phase packaged gas/electric up to 11.3 eer/80% afue

Advertisement

Quick Links

Standard Features
• R-410A chlorine-free refrigerant
• TuffTube™ tubular heat exchanger
• High-efficiency scroll compressors
• Two-stage heating and cooling
• Copper tube / aluminum fin coils
• Power block for field wiring
• High-capacity, steel-cased filter drier
• Single-point entry
• 24-volt terminal strip
• Convertible airflow orientation
• Built-in filter rack with
standard 2" filters
• Complies with California Low
NOx emissions standards
• AHRI Certified; ETL Listed
