Table of Contents
Section 3
viii
Repair Procedures .............................................................................................. 19
Introduction ........................................................................................................... 19
Platform Controls ............................................................................................... 21
Platform Controls .................................................................................................. 21
1-1 Platform Circuit Board .................................................................................... 21
How to Remove the LED Circuit Board ........................................................... 23
1-2 Joysticks - How to Calibrate a Joystick .......................................................... 23
How to Reset a Proportional Valve Coil Default .............................................. 27
How to Set the Function Thresholds and Default Functions Speeds.............. 28
How to Adjust the Function Speeds ................................................................ 30
How to Adjust the Function Ramp Rate Setting .............................................. 31
Platform Components ........................................................................................ 32
2-1 Platform .......................................................................................................... 32
2-2 Platform Leveling Cylinder ............................................................................. 33
2-3 Platform Rotator ............................................................................................. 34
How to Bleed the Platform Rotator .................................................................. 35
2-4 Platform Level Sensor - How to Calibrate the Platform Level Sensor ........... 36
2-5 Platform Overload System (if equipped) ........................................................ 37
2-6 Platform Overload Recovery Message .......................................................... 39
