7 Enter sensor calibration mode by pressing the
buttons at the ground controls in the following
sequence: (plus)(enter)(enter)(plus).
8 Press the enter or previous button on the
LCD screen until DELETE AXLE ANGLE
SENSORS CALIBRATION is displayed.Press
the plus button to select YES, then press the
enter button to accept.
9 At the AXLE ANGLES FULLY RETRACTED
screen, press the plus button to select YES,
then press the enter button to accept.
10 When the AXLE ANGLES FULLY EXTENDED
screen is displayed, start the engine and fully
extend the axles.
Note: If the system exits out of calibration mode
when the engine is started, repeat step 10.
11 Press the plus button to select YES, then
press the enter button to accept.
12 Press the enter or previous button on the
LCD screen until EXIT is displayed.
13 Press the plus button to select YES, then
press the enter button to accept.
14 Press and hold the engine start button for
approximately 5 seconds to shut off the
engine and to save the calibration settings.
Note: Do not turn the engine off with the key switch
or red Emergency Stop button or all calibration
points or values will not be saved.
Part No. 1268558GT
15 Wait approximately 20 seconds and turn the
machine off by pressing the red Emergency
Stop button in.
16 Remove the fastener that was temporarily
installed. Close the control box door and install
the door retaining fasteners.
Note: When the control box door is closed, the
calibration toggle switch is automatically activated
to exit out of calibration mode.
17 Turn the key back to the run position and
remove the key from the bypass/recovery key
switch. Insert the key into the main key switch
and turn it to ground controls.
Note: Be sure that the bypass/recovery key switch
is in the run position before attempting to operate
the machine.
