Terex Genie ZX-135/70 Service And Repair Manual page 201

March 2018
SPN = Suspect Parameter Number
FMI = Failure Mode Identifier
SPN FMI Description
3219 15 After treatment #1 Intake Gas Sensor at Temperature : High- least
severe (1)
3219 17 After treatment #1 Intake Gas Sensor at Temperature : Low - least
severe (1)
3222 3 After treatment #1 Intake Gas Sensor Heater : Voltage Above
Normal
3222 4 After treatment #1 Intake Gas Sensor Heater :Voltage Below
Normal
3222 5 After treatment #1 Intake Gas Sensor Heater :Current Below
Normal
3242 3 Particulate Trap Intake Gas Temperature :Voltage Above Normal
3242 4 Particulate Trap Intake Gas Temperature :Voltage Below Normal
3251 0 Particulate Trap Differential Pressure : High- most severe (3)
3251 3 Particulate Trap Differential Pressure:Voltage Above Normal
3251 4 Particulate Trap Differential Pressure :Voltage Below Normal
3251 7 Particulate Trap Differential Pressure :Not Responding Properly
3251 10 Particulate Trap Differential Pressure :Abnormal Rate of Change
3251 16 Particulate Trap Differential Pressure :High-moderate severity (2)
3251 17 Particulate Trap Differential Pressure : Low - least severe (1)
3509 2 Sensor Supply Voltage 1: Erratic,Intermittent,or Incorrect
3510 2 Sensor Supply Voltage 2 : Erratic,Intermittent, or Incorrect
3511 2 Sensor Supply Voltage 3 : Erratic,Intermittent,or Incorrect
3697 6 Particulate Trap Lamp Command :Current Above Normal
3698 6 Exhaust System High Temperature Lamp Command :Current
Below Normal
Part No. 1268558GT
Perkins 854F-34T Engine Fault Code
ZX®-135/70
Service and Repair Manual
Refer to Engine Manual
Oxygen Level- Test
Oxygen Level- Test
Oxygen Level- Test
Oxygen Level- Test
Oxygen Level- Test
Engine Temperature Sensor
Open or Short Circuit- Test
Engine Temperature Sensor
Open or Short Circuit- Test
Diesel Particulate Filter Collects
Excessive Soot
Engine Pressure Sensor Open or
Short Circuit - Test
Engine Pressure Sensor Open or
Short Circuit- Test
Diesel Particulate Filter Has
Differential Pressure Problem
Diesel Particulate Filter Has
Differential Pressure Problem
Diesel Particulate Filter Collects
Excessive Soot
Diesel Particulate Filter Has
Differential Pressure Problem
5 Volt Sensor Supply Circuit-
Test
5 Volt Sensor Supply Circuit-
Test
5 Volt Sensor Supply Circuit -
Test
Indicator Lamp Circuit- Test
Indicator Lamp Circuit- Test
