Pictorial index

For safety

1

and security

Instrument

2

cluster

Operation of

each

3

component

Driving

4

Audio system

5

Interior features

6

Maintenance

7

and care

When trouble

8

arises

Vehicle

9

specifications

For owners

10

Index

PRIUS c_U

Search by illustration

Make sure to read through them

How to read the gauges and meters, the variety of

warning lights and indicators, etc.

Opening and closing the doors and windows,

adjustment before driving, etc.

Operations and advice which are necessary for

driving

Operating the audio system

Usage of the interior features, etc.

Caring for your vehicle and maintenance

procedures

What to do in case of malfunction or emergency

Vehicle specifications, customizable features, etc.

Reporting safety defects for U.S. owners, and seat

belt and SRS airbag instructions for Canadian

owners

Search by symptom

Search alphabetically

Table of Contents

Advertisement

Chapters

Table of Contents

Troubleshooting

Need help?

Need help?

Do you have a question about the PRIUS C 2019 and is the answer not in the manual?

Questions and answers

Summary of Contents for Toyota PRIUS C 2019

Page 1 Pictorial index Search by illustration For safety Make sure to read through them and security Instrument How to read the gauges and meters, the variety of cluster warning lights and indicators, etc. Operation of Opening and closing the doors and windows, each adjustment before driving, etc.
Page 2: Table Of Contents
TABLE OF CONTENTS For your information....... 8 Instrument cluster Reading this manual ....14 How to search......15 Pictorial index ......16 Instrument cluster Warning lights For safety and security and indicators ....92 Gauges and meters ..... 97 Multi-information 1-1.
Page 3 4-4. Refueling Driving Opening the fuel tank cap......219 4-5. Toyota Safety Sense C 4-1. Before driving Toyota Safety Sense C..223 Driving the vehicle..... 170 Cargo and luggage.... 179 (Pre-Collision System)..229 Vehicle load limits ..... 183 Trailer towing..... 184 (Lane Departure Alert)..
Page 4 TABLE OF CONTENTS 5-6. Playing an audio CD and Audio system MP3/WMA/AAC discs (Multimedia system) CD player operation... 298 5-1. Using the audio system 5-7. Using an external device Audio system types ... 278 (Multimedia system) 5-2. Basic Operations Listening to an iPod ... 304 (Multimedia system) Listening to a USB Multimedia system ....
Page 5 ® 5-9. Bluetooth Audio Interior features (Multimedia system) ® Listening to Bluetooth Audio....... 328 6-1. Using the air ® 5-10. Bluetooth phone conditioning system (Multimedia system) and defogger ® Using a Bluetooth Automatic air Phone......330 conditioning system..374 Making a call ..... 333 Seat heaters ......
Page 6 TABLE OF CONTENTS Maintenance and care When trouble arises 7-1. Maintenance and care 8-1. Essential information Cleaning and protecting Emergency flashers... 466 the vehicle exterior..398 If your vehicle has Cleaning and protecting to be stopped in the vehicle interior... 401 an emergency....
Page 7 Vehicle specifications Index 9-1. Specifications What to do if... (Troubleshooting)..... 580 Maintenance data (fuel, oil level, etc.) ..534 Alphabetical index ...... 585 Fuel information ....543 Tire information ....546 9-2. Customization Customizable features ..558 Items to initialize....563 For owners Reporting safety defects for U.S.
Page 8: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available on the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 9 ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. High voltage parts and cables on the hybrid vehicles emit approximately the...
Page 10 ● Data Transmission Your vehicle may transmit the data recorded in these computers to Toyota without notification to you. ● Data usage Toyota may use the data recorded in this computer to diagnose malfunc- tions, conduct research and development, and improve quality.
Page 11 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 12 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 13 PRIUS c_U...
Page 14: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. 1 2 3 Indicates operating or working procedures.
Page 15: How To Search
How to search Searching by name ■ • Alphabetical index ..P. 585 Searching installation ■ position • Pictorial index....P. 16 Searching by symptom or ■ sound • What to do if... (Troubleshooting) ..P. 580 Searching by title ■ • Table of contents .....P. 2 PRIUS c_U...
Page 16: Pictorial Index
Pictorial index Pictorial index ■ Exterior Doors ......... . . P. 125 Locking/unlocking .
Page 17 Pictorial index Windshield wipers ....... . . P. 212 Precautions against winter season ..... P. 272 Fuel filler door .
Page 18 Pictorial index ■ Instrument panel Power switch ....... . . P. 186, 190 Starting the hybrid system/changing the modes .
Page 19 Pictorial index Turn signal lever ........P. 204 Headlight switch .
Page 20 Pictorial index ■ Switches Automatic High Beam switch ......P. 244 Outside rear view mirror switches ....P. 159 Instrument panel light control dial .
Page 21 Pictorial index Audio remote control switches ..... P. 281 Meter control switches ......P. 102 Cruise control switch .
Page 22 Pictorial index Seat heater switches ......P. 382 VSC OFF switch ........P. 264 Eco drive mode switch .
Page 23 Pictorial index ■ Interior SRS airbags ........P. 39 Floor mats .
Page 24 Pictorial index Inside rear view mirror ......P. 158 Sun visors ........P. 391 Vanity mirrors.
Page 25 For safety and security 1-1. For safe use Before driving...... 26 For safe driving ....28 Seat belts ......30 SRS airbags......39 Front passenger occupant classification system ..52 Safety information for children ......57 Child restraint systems..58 Installing child restraints..
Page 26: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 27 When installing the driver's floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver's seat. ●...
Page 28: For Safe Driving
1-1. For safe use For safe driving For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 29 1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (P. 158, 159) WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ●...
Page 30: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 31 1-1. For safe use Rear center seat belt Fastening the seat belt ■ The rear center seat belt is a 3-point type restraint with 2 buckles. Both seat belt buckles must be correctly located and securely latched for proper operation. Push the tabs back all the way into the cover and then remove the tabs.
Page 32 1-1. For safe use Releasing the seat belt ■ Release the rear center seat belt only when necessary, such as when folding down the rear seat. For safety, always store the plate in the designated place after releasing it. To release tab “A”, press the release button.
Page 33 1-1. For safe use Holding tab “A” and “B” together, insert both tabs all the way into the cover on the roof. With tab “B” inserted all the way into the cover, move tab “A” slightly back toward the cover’s inlet, so that it blocks the inlet.
Page 34 1-1. For safe use Seat belt pretensioners (front seats) The pretensioners help the seat belts to quickly restrain the occu- pants by retracting the seat belts when the vehicle is subjected to certain types of severe frontal or side collision or a vehicle rollover. The pretensioners do not activate in the event of a minor frontal impact, a minor side impact or a...
Page 35 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 36 ● If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. PRIUS c_U...
Page 37 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there’s no obvious damage.
Page 38 1-1. For safe use WARNING ■ Using a seat belt extender ● Do not wear the seat belt extender if you can fasten the seat belt without the extender. ● Do not use the seat belt extender when installing a child restraint system because the belt will not securely hold the child restraint system, increas- ing the risk of death or serious injury in the event of an accident.
Page 39: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
Page 40 1-1. For safe use ◆ SRS side and curtain shield airbags SRS front side airbags Can help protect the torso of the front seat occupants. SRS curtain shield airbags ● Can help protect primarily the head of occupants in the outer seats ●...
Page 41 1-1. For safe use SRS airbag system components Curtain shield airbags Driver’s seat cushion airbag SRS warning light and “AIR Side impact sensors (front) BAG ON” and “AIR BAG OFF” Seat belt pretensioners and indicator lights force limiters Front side airbags Side impact sensors (front Side impact sensors (rear) door)
Page 42 1-1. For safe use Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors etc. shown in the system compo- nents diagram above.
Page 43 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 44 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger. ● Do not allow the front seat occupants to hold items on their knees.
Page 45 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not attach anything to areas such as a door, windshield glass, side door glass, front or rear pillar, roof side rail and assist grip. ● Vehicles without a smart key system: Do not attach any heavy, sharp or hard objects such as keys and accessories to the key.
Page 46 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 47 1-1. For safe use ■ If the SRS airbags deploy (inflate) ● Slight abrasions, burns, bruising etc., may be sustained from SRS airbags, due to the extremely high speed deployment (inflation) by hot gases. ● A loud noise and white powder will be emitted. ●...
Page 48 1-1. For safe use ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags and SRS curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
Page 49 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 50 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ●...
Page 51 1-1. For safe use ● The portion of the front pillars, rear pil- lars or roof side rail garnishes (padding) containing the SRS curtain shield air- bags inside is scratched, cracked, or otherwise damaged. PRIUS c_U...
Page 52: Front Passenger Occupant Classification System
1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classi- fication system. This system detects the conditions of the front passenger seat and activates or deactivates the front passenger airbag and seat cushion airbag in the front passenger side. U.S.A.
Page 53 1-1. For safe use Condition and operation in the front passenger occupant classi- fication system Adult ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Activated Devices...
Page 54 1-1. For safe use Child restraint system with infant ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights OFF” Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Devices Deactivated Seat cushion airbag in the front passenger side Unoccupied ■...
Page 55 1-1. For safe use : The system judges a person of adult size as an adult. When a smaller adult sits in the front passenger seat, the system may not recognize him/ her as an adult depending on his/her physique and posture. : In the event the front passenger is wearing a seat belt.
Page 56 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 57: Safety Information For Children
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 58: Child Restraint Systems
1-1. For safe use Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the LATCH anchors or the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 59 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Rear facing — Infant seat/con- Forward facing — Convertible   vertible seat seat Booster seat ...
Page 60 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 61 1-1. For safe use WARNING ■ Child restraint precautions ● Do not allow the child to lean his/her head or any part of his/her body against the door or the area of the seat, front and rear pillars or roof side rails from which the SRS side airbags or SRS curtain shield airbags deploy even if the child is seated in the child restraint system.
Page 62: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Children) system.
Page 63 1-1. For safe use Installation with LATCH system Remove the head restraint (P. 153) Widen the gap in the seat cushion slightly. Flip up and fold the cover, and fix it with the hook-and-loop fas- tener. Type A  Latch the hooks of the lower straps onto LATCH...
Page 64 1-1. For safe use Type B  Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. For owners in Canada: The symbol on a child restraint system indicates the presence of a lower connector system.
Page 65 1-1. For safe use Installing child restraints using a seat belt (child restraint lock function belt) Rear facing  Infant seat/convertible seat ■ Place the child restraint sys- tem on the rear seat facing the rear of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle.
Page 66 1-1. For safe use Fully extend the shoulder belt and allow it to retract to put it in lock mode. In lock mode, the belt cannot be extended. While pushing child restraint system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 67 1-1. For safe use Forward facing  Convertible seat ■ Rear center seat: Adjust the head restraint to the upmost posi- tion. (  P. 153) Place the child restraint sys- tem on the seat facing the front of the vehicle. Run the seat belt through the child restraint system and insert the plate into the...
Page 68 1-1. For safe use While pushing child restraint system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 69 1-1. For safe use Booster seat ■ Place the child restraint sys- tem on the seat facing the front of the vehicle. Sit the child in the child restraint system. Fit the seat belt to the child restraint sys- tem according to the manu- facturer’s instructions insert the plate into the...
Page 70 1-1. For safe use Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap Remove the luggage cover (if equipped). (P. 395) Remove the head restraint (P.
Page 71 1-1. For safe use WARNING ■ When installing a booster seat To prevent the belt from going into ALR lock mode, do not fully extend the shoulder belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to the child. (P. 34) ■...
Page 72 1-1. For safe use WARNING ■ When installing a child restraint system ● Shake the child restraint system left and right, and forward and backward to ensure that it has been securely installed. ● After securing a child restraint system, never adjust the seat. ●...
Page 73: Exhaust Gas Precautions
Keep the back door closed. ● If you smell exhaust gases in the vehicle even when the back door is closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking ●...
Page 74: 1-2. Hybrid System
1-2. Hybrid system Hybrid system features Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the characteristics of your vehicle, and operate it with care. The hybrid system combines the use of a gasoline engine and an electric motor (traction motor) according to driving condi- tions, improving fuel efficiency and reducing exhaust emis- sions.
Page 75 1-2. Hybrid system ◆ When stopped/during start off The gasoline engine stops when the vehicle is stopped. During start-off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped and the motor is used.
Page 76 1-2. Hybrid system ■ Regenerative braking In the following situations, kinetic energy is converted to electric energy and deceleration force can be obtained in conjunction with the recharging of the hybrid battery (traction battery). ● The accelerator pedal is released with the shift lever in D or B. ●...
Page 77 30 minutes or 10 miles (16 km). If the hybrid battery (traction battery) becomes fully discharged and you are unable to start the hybrid system, contact your Toyota dealer. ■ Charging the 12-volt battery P.
Page 78 When in the area surrounding the rear of the vehicle, rather than in front of the vehicle ■ Maintenance, repair, recycling, and disposal Contact your Toyota dealer regarding maintenance, repair, recycling and dis- posal. Do not dispose of the vehicle yourself. ■ Customization that can be configured at Toyota dealer Settings (e.g.
Page 79: Hybrid System Precautions
1-2. Hybrid system Hybrid system precautions Take care when handling the hybrid system, as it is a high volt- age system (about 520 V at maximum) as well as contains parts that become extremely hot when the hybrid system is operating. Obey the warning labels attached to the vehicle.
Page 80 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer. Hybrid warning message A message is automatically displayed when a malfunction occurs in the hybrid system or an improper operation is attempted.
Page 81 If a warning light comes on, a warning message is displayed, or the 12- volt battery has been disconnected The hybrid system may not start. In this case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer. ■ Running out of fuel...
Page 82 1-2. Hybrid system WARNING ■ High voltage and high temperature precautions This vehicle has high voltage DC and AC systems as well as a 12-volt sys- tem. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury. ●...
Page 83 1-2. Hybrid system WARNING ■ Road accident cautions Observe the following precautions to reduce the risk of death or serious injury: ● Pull your vehicle off the road, apply the parking brake, shift the shift lever to P, and turn the hybrid system off. ●...
Page 84 Toyota dealer or a qualified service shop. If the hybrid battery is not dis- posed of properly, it may cause electric shock that can result in death or serious injury.
Page 85 Do not carry large amounts of water such as water cooler bottles in the vehicle. If water spills onto the hybrid battery (traction battery), the battery may be damaged. Have the vehicle inspected by your Toyota dealer. ● There is a filter installed to the air intake vent. When the filter remains noticeably dirty even after cleaning the air intake vent, filter cleaning or replacement is recommended.
Page 86: 1-3. Theft Deterrent System
1-3. Theft deterrent system  Immobilizer system The vehicle’s keys have built-in transponder chips that prevent the hybrid system from starting if a key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 87 1-3. Theft deterrent system ■ Certifications for the immobilizer system For vehicles sold in the U.S.A. and Puerto Rico  PRIUS c_U...
Page 88 1-3. Theft deterrent system For vehicles sold in Canada  WARNING ■ Certifications for the immobilizer system Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTICE ■ To ensure the system operates correctly Do not modify or remove the system.
Page 89: Theft Prevention Labels
1-3. Theft deterrent system Theft prevention labels These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recov- ery of parts from stolen vehicles. Do not remove under penalty of law. PRIUS c_U...
Page 90 1-3. Theft deterrent system PRIUS c_U...
