Summary of Contents for Toyota PRIUS C 2019
- Page 1 PRIUS C 2 0 1 9 QUICK REFERENCE GUIDE...
- Page 2 Owner’s Manual. Each box contains safe operating instructions to help you avoid injury or equipment malfunction. All information in this Quick Reference Guide is current at the time of printing. Toyota reserves the right to make changes at any time without notice.
- Page 3 Tilt & telescopic steering wheel Vehicle Stability Control (VSC)/ TRAC OFF switch USB media/AUX port Windows-Power Windshield wipers & washers Visit your Toyota dealer for information on customizing this feature. Programmable by customer. Refer to the Owner’s Manual for instructions and more information.
-
Page 4: Instrument Panel
OVERVIEW Instrument panel Meter control switches Audio control switches Voice command switch Steering wheel controls Telephone Cruise control switch switch Headlight and turn signal controls Windshield wiper and washer controls Automatic High Beam (AHB) switch Power outside rear view mirror controls Instrument panel light control dial Lane Departure Alert (LDA) switch Pre-Collision System (PCS) switch... - Page 5 If equipped. For details, refer to the “Navigation and Multimedia System Owner’s Manual” and “2019 Entune™ Audio Quick Reference Guide.” Emergency flasher button Meters/Multi-Information Display (MID) Audio/Navigation system Air conditioning controls USB media/AUX port LOWER CENTER CONSOLE SWITCHES Vehicle Stability Control (VSC) OFF switch “EV MODE”...
-
Page 6: Instrument Cluster
OVERVIEW Instrument cluster Transmission shift Outside temperature position indicator Multi-Information Display Speedometer Clock Fuel gauge Average fuel consumption Odometer/trip meter Service indicators and reminders Indicator symbols For details, refer to “Indicators and warning lights,” Section 2, 2019 Owner’s Manual. AIR BAG ON/OFF indicator Airbag SRS warning Anti-lock Brake System (ABS) warning Arrow direction indicates fuel tank door position... - Page 7 If the indicator does not turn off within a few seconds of starting the Hybrid system, there may be a malfunction. Have the vehicle inspected by your Toyota dealer. If the indicator flashes, there may be a malfunction. Refer to the Owner’s Manual.
-
Page 8: Keyless (And Remote) Entry
OVERVIEW Keyless (and remote) entry UNLOCKING OPERATION Smart Key Carry remote Smart Key Front door unlock* Grasp Push ONCE: Driver door TWICE: All doors NOTE: If a door is not opened within 60 seconds of unlocking, all doors will relock for safety. -
Page 9: Smart Key System (If Equipped)
Smart Key system (if equipped) START FUNCTION NOTE: The smart key must be carried to enable the start function. With the Park position selected and the brake pedal depressed, push the “POWER” switch. POWER (WITHOUT STARTING HYBRID SYSTEM) Without depressing the brake pedal, pressing the “POWER” switch will change the operation mode in succession from: Accessory –... -
Page 10: Hood Release
OVERVIEW Hood release Pull Pull up latch and raise hood Engage support rod Instrument panel light control Brightness control... -
Page 11: Engine Maintenance
Engine maintenance Windshield washer fluid tank Engine oil filler cap Engine oil level dipstick Engine coolant reservoir NOTE: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance. Please refer to the “Warranty & Maintenance Guide.” Maintenance reset light instructions can be found in “Maintenance Requirements Chapter”... -
Page 12: Features & Operations
FEATURES & OPERATIONS Hybrid Synergy Drive System The Hybrid Synergy Drive System utilizes a computer-controlled gasoline engine and electric motor to provide the most efficient combination of power for the vehicle. To conserve energy, when the brakes are applied the braking force generates electricity which is then sent to the traction battery. -
Page 13: Hybrid Transmission
Hybrid transmission Park Reverse Neutral Drive Engine brake The “POWER”/ignition switch must be “ON” and the brake pedal depressed to shift from Park. The engine brake is the equivalent of downshifting. Shift to “B” when engine braking is desired (e.g. downhill driving, coasting to a stop). Drive mode ECO MODE Push... -
Page 14: Seats-Head Restraints
FEATURES & OPERATIONS Seats-Head restraints FRONT (ADJUSTABLE TYPE)/REAR CENTER Lock release button REAR OUTBOARD Lock release buttons Seat adjustments-Front Seatback angle Height crank Seat position (forward/backward) (driver’s side; if equipped) -
Page 15: Seat-Folding Down Rear Seat
Seat-Folding down rear seat SPLIT REAR SEATS (1) Pull up (2) Fold down Steering lock release Without Smart Key system With Smart Key system Turn Turn Turn Push When starting the hybrid system, the “STEERING LOCK ACTIVE” will be power switch may seem stuck in the displayed on the multi-information “LOCK”... -
Page 16: Lights & Turn Signals
Refer to Toyota Safety Sense™ C (TSS-C) in this guide or the Owner’s Manual for more details on the Automatic High Beam feature. * Operating conditions must be met. Refer to Owner’s Manual for details. -
Page 17: Windshield Wipers And Washers
Windshield wipers & washers FRONT Single wipe Adjust frequency Interval wipe Slow Pull to wash and wipe Fast Intermittent windshield wiper frequency adjustment Rotate to increase/ decrease wipe frequency. (if equipped) REAR Wash and wipe Wipe Interval wipe Wash and wipe * The wipers will automatically operate a couple of times after the washer squirts. -
Page 18: Air Conditioning/Heating
FEATURES & OPERATIONS Air conditioning/heating Temperature setting display Fan speed display Airflow mode display Automatic climate control ON Adjusting the temperature setting will cause Windshield defogger the airflow vents, air intake and fan to adjust automatically. Recirculate cabin air (outside air when OFF) Rear window defogger Airflow vent In “... -
Page 19: Auto Lock/Unlock
Auto lock/unlock Automatic door locks can be programmed to operate in different modes, or turned OFF. Shift position linked door locking/unlocking function -Doors lock when shifting from Park. -Doors unlock when shifting into Park. Speed linked door locking function -Doors lock when the vehicle speed goes above approximately 12 mph. Driver’s door linked door unlocking function -(Vehicles without a Smart Key system) Doors unlock when the driver’s door is opened within 45 seconds after the engine switch is set from “ON”... -
Page 20: Entune ™ Audio
FEATURES & OPERATIONS Audio ENTUNE AUDIO ™ Push to access Bluetooth hands-free Eject CD Touch screen display system Seek station/ CD track select Turn to tune radio stations Push to turn manually or ON/OFF select tracks or files Push to display audio screen ENTUNE... -
Page 21: Usb Media/Aux Port
USB media/AUX port USB media port By connecting a USB-compatible portable audio device or USB memory stick into the USB media port, you can listen to music through the vehicle’s speaker system. AUX port By inserting an AUX cable into the AUX port, you can listen to music from a portable audio device through the vehicle’s speaker system while in AUX mode. -
Page 22: Cruise Control
FEATURES & OPERATIONS Cruise control TURNING SYSTEM ON/OFF System ON/OFF FUNCTIONS Increase speed Resume Cancel Decrease speed The set speed may also be cancelled by depressing the brake pedal. The set speed may be resumed once vehicle speed exceeds 25 mph. Parking brake Release (2) Push... -
Page 23: Tilt And Telescopic Steering Wheel
Tilt & telescopic steering wheel Angle Lock release lever Length Hold wheel, push lever down, set angle and length, and return lever. NOTE: Do not attempt to adjust while the vehicle is in motion. Multi-Information Display (MID) Display Meter controls : Select menu : Sroll up/down Enter/select... - Page 24 FEATURES & OPERATIONS Steering wheel switches ® & telephone controls (Bluetooth Steering wheel telephone switches “MODE” Push to change the audio source. Push and hold to mute or pause the audio. “ ” Use to search within the selected audio medium (radio, etc.). Voice command switch End call Volume control...
-
Page 25: Hill-Start Assist Control (Hac)
Hill-start Assist Control (HAC) Brake pedal HAC helps prevent rolling backwards on an incline. To engage, push the brake pedal farther down while at a complete stop until a beep sounds and slip indicator illuminates. HAC holds for approximately two seconds after releasing brake pedal. Refer to the Owner’s Manual for more details. -
Page 26: Toyota Safety Sense
TOYOTA SAFETY SENSE ™ Quick overview-Toyota Safety Sense™ C (TSS-C) Toyota Safety Sense C (TSS-C) is a set of active safety technologies designed to ™ help mitigate or prevent collisions across a wide range of traffic situations, in certain conditions. TSS-C is designed to help support the driver’s awareness, decision making and vehicle operation contributing to a safe driving experience. -
Page 27: Pre-Collision System With Pedestrian Detection (Pcs W/Pd)
Refer to a Toyota Owner’s Manual for a list of additional situations in which the system may not operate properly. Pre-Collision Warning... -
Page 28: Pedestrian Detection Function
In certain conditions, the PCS system included with the TSS-C package may also help to detect a pedestrian in front of your vehicle. With Toyota Safety Sense™ C, PCS uses an in-vehicle camera and lasers to help detect a pedestrian in front of your vehicle in certain conditions. -
Page 29: Lane Departure Alert (Lda)
The system can be disabled/enabled and the alert timing of the system can be changed. (Alert timing only, brake operation remains the same). Refer to a Toyota Owner’s Manual for additional information on PCS w/PD operation, settings adjustments, limitations, and precautions before attempting to use it. -
Page 30: Lane Departure Alert
Ignition cycle until changed by the driver or the system is reset. Refer to the Toyota Owner’s Manual for additional information on LDA operation, settings adjustments, limitations, and precautions before attempting to use it. LANE DEPARTURE ALERT The LDA function displays when the Multi-Information Display (MID) is switched to the driving assist system information screen. -
Page 31: Automatic High Beams (Ahb)
By using high beams more frequently, the system may allow earlier detection of pedestrians and obstacles. Refer to the Toyota Owner’s Manual for additional information on AHB operation, settings adjustments, limitations, and precautions before attempting to use it. -
Page 32: Safety & Emergency Features
If the tire pressure indicator flashes for more than 60 seconds and then remains on, take the vehicle to your local Toyota dealer. NOTE: The warning light may come on due to temperature changes or changes in tire pressure from natural air leakage. If the system has not been initialized recently, setting the tire pressures to factory specifications should turn off the light. -
Page 33: Rear Door Child Safety Locks
Rear door child safety locks Rear door Lock Moving the lever to the lock position will allow the door to be opened only from the outside. Spare tire & tools Tool location Luggage floor cover Jack Spare wheel cushions Tool bag Spare tire For detailed directions on removing the jack from under the driver’s seat, refer to the Owner’s Manual. -
Page 34: Star Safety System
ANTI-LOCK BRAKE SYSTEM (ABS) Toyota’s ABS sensors detect which wheels are locking up and limits wheel lockup by “pulsing” each wheel’s brakes independently. Pulsing releases brake pressure repeatedly for fractions of a second. This helps the tires attain the traction that current road conditions will allow, helping you to stay in directional control. -
Page 35: Traction Control (Trac)
Traction Control helps maintain traction on loose gravel and wet, icy, or uneven surfaces by applying brake force to the spinning wheel(s). Toyota’s TRAC sensors are activated when one of the drive wheels starts to slip. TRAC limits engine output and applies the brakes to the spinning wheel. This transfers power to the wheels that still have traction to help keep you on track. -
Page 36: Bluetooth ® Device Pairing Section
BLUETOOTH DEVICE PAIRING ® SECTION Do not attempt the Bluetooth Pairing process while driving. ®... - Page 37 Entune touch screen system Pairing your phone is the first step in connecting with your Toyota for hands-free calling and for audio streaming via Bluetooth. This pairing process is quick and easy: all Android mobile digital devices have Bluetooth integrated; all you have to do is setup the phone and multimedia system to “talk”...
-
Page 38: Bluetooth ® Device Pairing
Bluetooth on your Entune head unit. Please follow the instructions below to pair your Bluetooth enabled phone to your Entune system. STEP 6 STEP 7 STEP 8 On your Toyota Vehicle Entune Select BLUETOOTH. Select ADD, to add your Multimedia Head Unit, Select phone device. - Page 39 2. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Toyota is under license. A compatible Bluetooth enabled phone must first be paired. Phone performance depends on software, coverage & carrier.
- Page 40 Pairing process while driving.** ® Pairing your phone is the first step in connecting with your Toyota for hands-free calling and for audio streaming via Bluetooth. This pairing process is quick and easy: all iPhone mobile digital devices have Bluetooth integrated; all you have to do is setup the phone and multimedia system to “talk”...
- Page 41 Bluetooth on your Entune head unit. Please follow the instructions below to pair your Bluetooth enabled phone to your Entune system. STEP 6 STEP 7 STEP 8 On your Toyota Vehicle Entune Select BLUETOOTH. Select ADD, to add your Multimedia Head Unit, Select phone device.
- Page 42 2. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Toyota is under license. A compatible Bluetooth enabled phone must first be paired. Phone performance depends on software, coverage & carrier.
- Page 43 Pairing process while driving.** ® Pairing your phone is the first step in connecting with your Toyota for hands-free calling and for audio streaming via Bluetooth. This pairing process is quick and easy: all Windows Phone mobile digital devices have Bluetooth integrated; all you have to do is setup the phone and multimedia system to “talk”...
- Page 44 ® to pair your Bluetooth enabled phone to your Entune system. STEP 6 STEP 7 STEP 8 On your Toyota Vehicle Entune Select BLUETOOTH. Select ADD, to add your Multimedia Head Unit, Select phone device. Image shown is a sample SETUP BUTTON on the Home image, features may vary.
- Page 45 2. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Toyota is under license. A compatible Bluetooth enabled phone must first be paired. Phone performance depends on software, coverage & carrier.
- Page 46 NOTES...
- Page 48 CUSTOMER EXPERIENCE CENTER 1-800-331-4331 Printed in U.S.A. 07/18 18-MKG-12047 00505QRG19PRIC...
