Harken 44.2st Installation Service

Two speed self-tailing winch

Advertisement

Quick Links

44.2st
Two Speed Self-Tailing Winch

Required Tools

Screwdriver
Plastic Head Hammer or Mallet
Small Knife
Brush
Rags
Solvent
Oil
Grease

Parts List

008
038
768
6009
6047
6143
6144
27791
27804
27811
27812
27814
27815
27816
27817
27828
27841
27908
28169
32536
36208
36210
36214
37676
37678
37876
38597
38599
39131
701887
726073
726076
938098
938099
939132

Suggested Service Kits

BK4512
BK4513
When ordering parts, please include a
"B" before each number (i.e. B008).
Winch Parts
Installation
Service
Pawl
Pawl Spring
Thrust Washer
Screw
Screw
Top Screw
Screw
Plastic Washer
Base
Pawl Gear
Gear
Pawl Gear
Gear Shaft
Gear Shaft
Cover Plate
Ratchet Gear
Handle Socket
Washer
Red Line Ring
Top Cap
Springs Support
Lower Jaw
Chrome Stripper Arm
Spindle
Stripper Arm Support
Center Stem
Spring
Upper Jaw
Bronze Stripper Arm
Bearing
Bearing
Bearing
Aluminum Drum
Chrome Drum
Bronze Drum
10
008 Pawls
10
038 Springs
100 ml Grease
