5 Configuration of the system
Extended Status Word
Variable
name:
nvoExtendedStatusword
This variable contains the complete extended status word.
For more detailed information on the Extended Status Word, please refer to the
NB!
Please note that in the representation of the Extended Status Word in the LonMaker Browser, the Least Significant Bit (LSB) is to the
far left.
5
Digital Inputs
Variable
name:
nvoDigitInput
This variable contains the status of the digital inputs.
A logical 1, indicates that the input is On or active.
A logical 0, indicates that the input is Off or inactive.
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9
Bit 10-63
Analog Input (53)
Variable
name:
nvoAnIn1
This variable contains the value allocated to the analog input terminal 53.
This terminal can either be configured as a voltage input (0-10 V) or as a current input (0-20 mA), depending on the setting of switch S 201. The variable
type is changeable with the commissioning tool or LNS Plug-in in order to match the appropriate unit.
If the variable type of SNVT_lev_percent is selected, the relative scaling is from 0 V/mA to par. 6-11
High Current
30
SNVT
type:
SNVT_state_64
SNVT
type:
SNVT_state_64
SNVT
type:
Changeable
SNVT_volt
SNVT_amp_mil
SNVT_lev_percent
MG.11.E2.02 - VLT
Troubleshooting section of this manual.
Digital Input Terminal 33
Digital Input Terminal 32
Digital Input Terminal 29
Digital Input Terminal 27
Digital Input Terminal 19
Digital Input Terminal 18
Reserved for future terminals
Digital Input GP I/O Terminal X30/2
Digital Input GP I/O Terminal X30/3
Digital Input GP I/O Terminal X30/4
Reserved for future terminals
Value:
Min. Max.
0 V 10 V
0 mA 20 mA
0 % 100 %
Terminal 53 High Voltage
® is a registered Danfoss trademark
VLT® FC 100 LonWorks
State:
Boolean 1 bit x 64
State:
Boolean 1 bit x 64
Resolution:
0.1 V
0.1 mA
0,1 %
Terminal 53
or par. 6-13
