VLT® FC 100 LonWorks
5.3.4 Configuration Properties (nci)
Variable function
Max. motor speed [%]
Min. motor speed [%]
Nom. motor speed [RPM]
Nom. motor frequency [Hz]
Min. ramp-up time [s]
Min. ramp-down time [s]
Heartbeat time [s]
A range of network configuration variables (SCPT's) is available for configuration of the frequency converter parameters. These parameters require setting
only once, usually following installation.
NB!
Please note that the settings written to configuration properties (nci's) will be stored in the non-volatile memory. Continuous writing
to configuration properties may damage the non-volatile memory.

5.4 Network Variable Description - VSD Profile - input

5.4.1 Frequency Converter Speed Setpoint
Variable name:
nviDrvSpeedStpt
This input variable provides start / stop control and a speed reference.
Variable name
nciMaxSpeed
nciMinSpeed
nciNmlSpeed
nciNmlFreq
nciRampUpTime
nciRampDownTime
nciSndHrtBt
SNVT type: State:
SNVT_switch 0 (False)
1 (True)
1 (True)
1 (True)
0xFF (default)
MG.11.E2.02 - VLT ® is a registered Danfoss trademark
5 Configuration of the system
SNVT type Profile
SNVT_lev_percent VSD 6010
SNVT_lev_percent VSD 6010
SNVT_rpm VSD 6010
SNVT_freq_hz VSD 6010
SNVT_time_sec VSD 6010
SNVT_time_sec VSD 6010
SNVT_time_sec VSD 6010
Value: Command:
Any Stop
0 Running 0 %
1-200 Running 0.5 to 100 %
201-255 Running 100 %
Any AUTO (invalid, no action)
FC 100 pa-
rameter
4-13
4-11
1-25
1-23
3-41
3-42
-
5
35
