VLT® FC 100 LonWorks
Output variables
Variable function
Variable name
Status word
nvoStatusword
Drive output [%]
nvoOutputPcnt
Drive output [Hz]
nvoOutputHz
kWh counter
nvoDrvEnrg
DC Link Voltage
nvoDCVoltage
Motor thermal
nvoTempMtr
Inverter Thermal
nvoTempInvrtr
Closed loop feedback
nvoFeedback
Fanbelt broken
nvoBrokenBelt
Alarm flag
nvoAlarm
Warning flag
nvoWarning
Alarm word
nvoAlarmword
Warning word
nvoWarningword
Extended statusword
nvoExtendedStatusword
Digital inputs
nvoDigitInput
Analog Input (53)
nvoAnIn1
Analog Input (54)
nvoAnIn2
Analog Input (X30/11)
nvo101AnIn1
Analog Input (X30/12)
nvo101AnIn2
Analog Input (X42/1)
nvo109AnIn1
Analog Input (X42/3)
nvo109AnIn2
Analog Input (X42/5)
nvo109AnIn3
ECB option status
nvoECBstatus
Parameter access cmd.
nvoParamResponse
SNVT type
SNVT_state
SNVT_lev_percent
SNVT_freq_hz
SNVT_elec_kwh_l
SNVT_volt
SNVT_lev_cont
SNVT_lev_cont
SNVT_count_inc_f
SNVT_switch
SNVT_switch
SNVT_switch
SNVT_state_64
SNVT_state_64
SNVT_state_64
SNVT_state_64
SNVT_volt/SNVT_amp_mil/SNVT_lev_percent
SNVT_volt/SNVT_amp_mil/SNVT_lev_percent
SNVT_volt/SNVT_lev_percent
SNVT_volt/SNVT_lev_percent
SNVT_volt/SNVT_temp_p/SNVT_lev_percent
SNVT_volt/SNVT_temp_p/SNVT_lev_percent
SNVT_volt/SNVT_temp_p/SNVT_lev_percent
SNVT_state
UNVT_param_response
MG.11.E2.02 - VLT
®
is a registered Danfoss trademark
5 Configuration of the system
Profile
FC 100 par.
FC VSD
16-03
FC VSD
16-05
FC VSD
16-13
FC VSD
15-02
FC VSD
16-30
FC VSD
16-18
FC VSD
16-35
FC VSD
16-52
FC VSD
16-93
FC VSD
16-90
FC VSD
16-03
FC VSD
16-90 + 16-91
FC VSD
16-92 + 16-93
FC VSD
16-94 + 16-95
FC VSD
16-60
FC VSD
16-62
FC VSD
16-64
FC VSD
16-75
FC VSD
16-76
FC VSD
18-30
FC VSD
18-31
FC VSD
18-32
FC VSD
31-10
FC VSD
-
5
21
