PRODUCT DESCRIPTION
ARRAY AR 2000
60.8"
12.12" 10.3"
50.8"
8.8" 11.25"
7.47" 12.1"
Dimensions are in inches
(*) Mounting feet may be removed during installation to reduce the overall height by 2". Feet must be re-installed once boiler is in its
final location.
