PRODUCT DESCRIPTION
34 35 36
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15 Vertical return manifold
16
17 Horizontal return manifold
18
19
20
21
22 Vertical supply manifold
23
24
38
37
Description
Outer frame
Leg
Fan
Supply pipe
Purge valve
Gas pipe
Gas valve
Heat exchanger
Pump
Water shutoff valve
Flow meter
Flue pipe
Gas shutoff valve
Inner frame
Condensate trap
Relief valve
Gas connection
Air intake
Venting connection
Condensate drain
Relief valve drain
39
47
46
Item
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
12
48
45
44
43
40
41 42
Description
Burner head O-ring
Burner flange (outer)
Burner gasket
Sight glass combustion
Igniter
Burner tube
Burner flange (inner)
Gasket burner flange
Fan
Brass connection
Brass fitting
Flange (2")
Check valve
Pump
Flange (1 1/2")
Flue plastic flange
Flue pipe
90° bend (PP)
Clapet seal (EPDM)
Clapet valve
Vertical flue manifold
Condensate pipe outlet
Condensate trap
Condensate pipe inlet
