If a unit is installed on a roof curb other than a York
curb, you must apply gasketing to all surfaces that come
in contact with the unit underside.
Before lifting the unit, make sure that the unit weight is
distributed equally on the rigging cables so that it lifts
evenly.
Units may be moved or lifted with a forklift. Slotted openings in
the base rails are provided for this purpose.
THE LENGTH OF THE FORKS MUST BE A MINIMUM OF 60
INCHES.
All panels must be secured in place when the unit is
lifted.
The condenser coils must be protected from rigging
cable damage with plywood or other suitable material.
Table 3:ZF078-150 weights and dimensions
Size Weight (lbs.)
Model
(tons)
Shipping Operating
078
ZF 868
(6.5)
090
ZF 865
(7.5)
102
ZF 999
(8.5)
120
ZF 1051
(10)
150
ZF 1258
(12.5)
Johnson Controls Ducted Systems

Center of gravity

X Y
863 47.25 24.00
860 48.25 25.34
994 47.25 24.75
1046 45.00 25.50
1253 49.75 24.50
®
roof
A
Figure 5: Unit 4 point load weight
A
Figure 6: Unit 6 point load weight
Figure 7: Center of gravity
4 point load location (lbs.)
A B C D
165 186 272 240
169 200 266 225
196 221 306 271
224 229 300 294
229 291 410 323
LEFT
B
D
LEFT
C
B
F
Y
X
LEFT
6 point load location (lbs.)
A B C
108 117 127
110 122 137
128 139 151
148 151 153
147 171 202
5566018-YIM-B-1018
FRONT
C
FRONT
D
E
FRONT
D E F
185 170 157
182 163 146
209 192 177
201 198 195
284 241 207
