Roof curbs

E
Figure 15: ZF078-150 roof curb
Figure 16: ZF078-150 transition roof curb

Roof curb components

Item
A Return air
B Supply air
C Right side of the unit
D Front side of the unit
E 2 typ.
F Insulated deck under the condenser section
G Insulated deck under the compressor section
Johnson Controls Ducted Systems
80-5/8
20
20
6
30
50-1/2
30-1/2
50-1/2
76-5/8
94
D
Description
B
A
8 or 14
E
23 4
A
B
C
F
G
D
80-5/8
26
10
59-1/4
C
64-1/4
5566018-YIM-B-1018
