Unit components

A
V
U
T
S
®
Figure 4: Predator

component location

Figure 4 shows the ZF120 model. Table 1 lists the components of the unit.
Table 1: Component location table
Item
Terminal block for high-voltage connection
A
Smart Equipment™ control board with screw connector for thermostat
B
wiring and network connections
Disconnect location (optional disconnect switch)
C
Filter access (2 in. or 4 in. filter options)
D
Filter drier (solid core)
E
Micro-channel aluminum tube/aluminum fin condenser
F
Slide-out motor and blower assembly for easy adjustment and service
G
Belt-drive blower motor
H
VFD Location (optional)
I
Power ventor motor
J
20-gauge aluminized steel tubular heat exchanger for long life
K
(stainless steel option)
1. Roof curbs for transitioning from York Sunline™ footprint to the ZF Series footprints are also available (field-installed accessory).
Johnson Controls Ducted Systems
C
B
R
Q
Description
D
N
O
P
Item
Two-stage gas heating to maintain warm, comfortable
L
temperature
Intelligent control board for safe and efficient operation
M
Slide out drain pan with 1 inch NPT, female connection
N
Compressor #1 access (high-efficiency compressor)
O
Side entry power and control knockouts
P
Tooless door latch
Q
Roof curbs in eight-inch and fourteen-inch heights
R
Base rails with forklift slots (three sides) and lifting holes
S
Compressor #2 access (high-efficiency compressor)
T
Dual stage cooling for maximum comfort
U
Second model nameplate inside hinged access panel
V
