5566018-YIM-B-1018
Detail A
A
14.594
7.705
Detail B
5-3/8
Table 7:Gas inlet and drain components
Item Description
Gas pipe inlet
A
Gas exhaust vent
B
1 in. FPT
C
Table 8:ZF078-150 unit clearances
Direction
1
Top
Front
Rear
1. Units must be installed outdoors. make sure that overhanging structures or shrubs do not obscure the condenser air discharge
outlet.
2. Units may be installed on combustable floors made from wood or class A, B or C roof covering materials.
12
3.184
Ø 2.000
B
Ø 3.126
4.727
42 inch cabinet
C
Distance (in.)
72
36
36
A
3.184
Ø 2.000
17.541
7.715
4.737
50 3/4 inch cabinet
Direction
Right
Left
2
Bottom
Johnson Controls Ducted Systems
B
Ø 3.126
Distance (in.)
12
36
0
