Zf078-150 Unit Bottom Duct Openings - Johnson Controls ZF Series Installation Manual

6 13/16
6 13/16
LEFT
20 1/8 19 1/8
17 1/8
Figure 10: ZF078-150 unit bottom duct openings
Figure 10 shows the bottom power, control, and convenience outlet wiring entry.
Johnson Controls Ducted Systems
32 11/16
RETURN
AIR
27 1/2
18
Bottom condensate drain
14 1/2
16 3/8
18 1/16
89
SUPPLY
AIR
24
21
Bottom gas
supply entry
FRONT
Top view
3X Ø 0.875
Ø 2.469
5566018-YIM-B-1018
RIGHT
12 5/16
25 9/16
13
