ZF078-150 high static motor - with powered convenience outlet (continued)
Compressors
(each)
Size
Volt
(tons)
RLA LRA MCC
208 15.6 110 24
230 15.6 110 24
120
(10)
460 7.8 52 12
575 5.8 38.9 9
208 23.1 160 36
230 23.1 160 36
150
(12.5)
460 12.2 87 19
575 8.7 62 14
1. Minimum Circuit Ampacity.
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
30
OD fan Supply Pwr
Pwr exh
motors blower conv
motor
(each) motor outlet
FLA FLA FLA FLA
3.03 9.6 5.5 20
3.03 9.6 5.5 20
1.6 4.7 2.2 20
1.35 3.6 1.8 20
3.03 14 5.5 20
3.03 14 5.5 20
1.6 6.6 2.2 20
1.35 5.2 1.8 20
Electric heat option
Model kW Stages Amps
None - - -
E18 13.5 2 37.5
E24 18 2 50
E36 25.5 2 70.8
E54 40.6 2 112.7
None - - -
E18 18 2 43.3
E24 24 2 57.7
E36 34 2 81.8
E54 54 2 129.9
None - - -
E18 18 2 21.7
E24 24 2 28.9
E36 34 2 40.9
E54 54 2 65
None - - -
E18 18 2 17.3
E24 24 2 23.1
E36 34 2 32.7
E54 54 2 52
None - - -
E18 13.5 2 37.5
E24 18 2 50
E36 25.5 2 70.8
E54 40.6 2 112.7
None - - -
E18 18 2 43.3
E24 24 2 57.7
E36 34 2 81.8
E54 54 2 129.9
None - - -
E18 18 2 21.7
E24 24 2 28.9
E36 34 2 40.9
E54 54 2 65
None - - -
E18 18 2 17.3
E24 24 2 23.1
E36 34 2 32.7
E54 54 2 52
1
MCA Max fuse
1
MCA
with pwr breaker
(amps)
exh (amps) size (amps)
60.8 66.3 70
71.4 78.3 80
87 93.9 90
113 119.9 125
165.4 172.3 175
60.8 66.3 70
78.6 85.5 80
96.6 103.5 100
126.8 133.6 150
154.4 161.3 175
30.5 32.7 35
39.3 42 40
48.3 51 50
63.3 66 70
77.1 79.9 90
23.4 25.2 25
31.1 33.4 35
38.4 40.6 40
50.4 52.6 60
61.5 63.8 70
88.1 93.6 110
88.1 93.6 110
92.5 99.4 110
118.5 125.4 125
170.9 177.8 175
88.1 93.6 110
88.1 93.6 110
102.1 109 110
132.3 139.1 150
159.9 166.8 175
45.5 47.7 50
45.5 47.7 50
50.6 53.4 60
65.6 68.4 70
79.5 82.3 90
34.2 36 40
34.2 36 40
40.4 42.6 45
52.4 54.6 60
63.5 65.8 70
