PRODUCT DESCRIPTION
2.7 Size and Connections
ARRAY AR 800
12"
(*) Mounting feet may be removed during installation to reduce the overall height by 2". Feet must be re-installed once boiler is in its
final location.
4.1"
10"
5.9
7.9
Ø2.5"
11.9"
7.2"
8
29.4"
7.6"
17"
Ø6"
Ø6"
Ø2.5"
5.7"
Dimensions are in inches
