MSP 318
HDMI 2.0 KVM Fiber Extender Set
USER MANUAL
Article No: RGB-RD-UM-MSP318 E001
Revision No: V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MSP 318 and is the answer not in the manual?

Questions and answers

Summary of Contents for RGBlink MSP 318

  • Page 1 MSP 318 HDMI 2.0 KVM Fiber Extender Set USER MANUAL Article No: RGB-RD-UM-MSP318 E001 Revision No: V1.0...
  • Page 2: Table Of Contents

    Chapter 3 Caution..........................11 Chapter 4 Order Codes......................... 12 4.1 Product..........................12 4.2 Module..........................12 Chapter 5 Support ........................13 5.1 Contact Us........................13 Chapter 6 Appendix........................14 6.1 Specification........................14 6.2 Rack Installation......................16 6.3 Terms & Definitions......................17 6.3 Revision History....................... 22 MSP 318 User Manual...
  • Page 3: Declarations

    30 days after the transfer of risks. In the event of justified notice of compliant, RGBlink can repair the fault or provide a replacement at its own discretion within an appropriate period. If this measure proves to be impossible or unsuccessful, the purchaser can demand a reduction in the purchase price or cancellation of the contract.
  • Page 4: Operators Safety Summary

    Normal wear as well as normal maintenance are not subject to the guarantee provided by RGBlink either. The environmental conditions as well as the servicing and maintenance regulations specified in this manual must be complied with by the customer.
  • Page 5: Installation Safety Summary

    If there is damage, notify the shipping carrier immediately for all claims adjustments. Site Preparation The environment in which you install your MSP 315 should be clean, properly lit, free from static, and have adequate power, ventilation, and space for all components. MSP 318 User Manual...
  • Page 6: Chapter 1 Your Product

    Chapter 1 Your Product 1.1 In the Box 2×Power Adapter MSP 318 User Manual...
  • Page 7: Product Overview

    1.2 Product Overview MSP 318 is an Optical HDMI Extender that overcomes the length restriction of standard HDMI cables by using optical fiber to send high definition audio and video signals over large distances. It also built in USB for KVM keyboard mouse for HDMI KVM solution.It is also built in RS232/IR selection to extend the IR remote control and transfer RS-232 (up to 115kbps) in both directions, allows you to connect serial devices such as touch screens and barcode scanners.
  • Page 8 DIP switch for IR, RS232 and USB function LED indicator selection DC 12V/1.5 A Slot for SPF Fiber module 2 3.5mm phone jacks for TX and RX of IR for remote control, connect to PC to transmit serial command 1.2.2 RX MSP 318 User Manual...
  • Page 9 DIP switch for IR, RS232 and USB function LED indicator selection DC 12V/1.5A Slot for SPF Fiber module 2x3.5mm phone jacks for TX and RX of IR RS232,DB9 male ,to receive RS232 serial signal,allows users to use touch screen or barcode scanner. MSP 318 User Manual...
  • Page 10: Dimension

    1.2.3 Dimension Following is the dimension of MSP 318 TX and RX for your reference: MSP 318 User Manual...
  • Page 11: Chapter 2 Use Your Product

    2.1 Operation Steps 1. Use HDMI cable to connect HDMI port of bluray player or PC to “HDMI IN” on MSP 318 TX (transmitter) and connect “HDMI Out” on MSP 318 RX (receiver) to HDMI port on HD Display or projector by premium HDMI cable.
  • Page 12: Chapter 3 Caution

    Under HDMI 2.0 mode, recommend to use “PREMIUM certified” HDMI cable. IR Emitter/Receiver cable do not put too close to avoid mutually interference. This Device not support CEC The transmission distance based on 10G Fiber module 300M-60KM. MSP 318 User Manual...
  • Page 13: Chapter 4 Order Codes

    Chapter 4 Order Codes 4.1 Product 611-0014-00-0 MSP 318 (TX/RX Set) 4.2 Module 950-0002-00-0 SFP, Multi Mode, 300m Max 950-0003-00-0 SFP, Single Mode, 500m Max 950-0007-00-0 SFP, Single Mode, 2km Max 950-0004-00-0 SFP, Single Mode, 10km Max MSP 318 User Manual...
  • Page 14: Chapter 5 Support

    Chapter 5 Support 5.1 Contact Us MSP 318 User Manual...
  • Page 15: Chapter 6 Appendix

    RS232 1×DB9 (male) Definition Pin 2 Pin 3 Pin 5 2×USB Type A 2× 3.5mm Phone Jack Performance Supported Input SMPTE 720p@23.98/24/25/29.97/30/50/59.94/60 Resolutions 1080i@23.98/24/25/29.97/30/50/59.94/60 1080p@23.98/24/25/29.97/30/50/59.94/60 | 2160p@24/30/50/60 VESA 800x600@60 | 1024x768@60 | 1280x768@60 | 1280x1024@60 | MSP 318 User Manual...
  • Page 16 Working -10 ~45℃ Temperature Storage -30~70℃ Temperature Humidity 20 - 95% Weight Nett 0.27 kg(TX)0.27(RX) Packaged 0.9kg Dimensions 115mm × 93mm × 24mm (TX) Nett 115mm × 93mm × 24mm (RX) Packaged 160mm × 120mm×80mm (Set) MSP 318 User Manual...
  • Page 17: Rack Installation

    Step 1: Lock M3*10 brass standoffs in the position as the red arrow pointed in the following pic. Step 2: Lock M3*5 cross countersunk head screw in the position as the the red arrow pointed in the following pic. MSP 318 User Manual...
  • Page 18: Terms & Definitions

     “Color burst”: In color TV systems, a burst of subcarrier frequency located on the back porch of the composite video signal. This serves as a color synchronizing signal to establish a frequency and phase reference for the chroma signal. Color MSP 318 User Manual...
  • Page 19  “HDSDI”: The high-definition version of SDI specified in SMPTE-292M. This signal standard transmits audio and video with 10 bit depth and 4:2:2 color quantization over a single coaxial cable with a data rate of 1.485 Gbit/second. Multiple video resolutions exists including progressive 1280x720 and interlaced 1920x1080 MSP 318 User Manual...
  • Page 20 DB-9 or DB-25 connectors. This standard is used for relatively short-range communication and does not specify balanced control lines. RS-232 is a serial control standard with a set number of conductors, data rate, word length, and type of MSP 318 User Manual...
  • Page 21 (Compaq, DEC, IBM, Intel, Microsoft, NEC, and Northern Telecom). The goal was easy plug-and-play expansion outside the box, requiring no additional circuit cards. Up to 127 external computer devices may be added through a USB MSP 318 User Manual...
  • Page 22 4. It has a pixel by line resolution of 640×480 with a color palette of 16 bits and 256,000 colors.  “YCrCb”: Used to describe the color space for interlaced component video.  “YPbPr”: Used to describe the color space for progressive-scan (non-interlaced) component video. MSP 318 User Manual...
  • Page 23: Revision History

    Release Sophie All information herein is Xiamen RGBlink Science & Technology Co Ltd. excepting noted. RGBlink is a registered trademark of Xiamen RGBlink Science & Technology Co Ltd. While all efforts are made for accuracy at time of printing, we reserve the right to alter otherwise make change without notice.
