- Page 1 MSP 214 USER MANUAL Article No: RGB-RD-UM-M214 E003 Revision No: V1.3...
-
Page 2: Table Of Contents
Installation Safety Summary ................4 Chapter 1 Your Product ..................6 1.2 Product Overview ..................7 1.2.1 MSP 214 DVI to Fiber Panel ..............8 1.2.2 MSP 214 Fiber Panel to DVI ..............10 1.2.3 Dimension .................... 12 Chapter 2 Installing Your Product ..............13 2.1 MSP 214 DVI to Fiber ................. - Page 3 3.2 Signal indicator light is off or blinks ............15 3.3 12V power interface poor contact ............15 Chapter 4 Ordering Codes .................. 16 4.1 Product ....................... 16 Chapter 5 Technical Support ................17 5.1 Contact Us ....................17 Chapter 6 Appendix .................... 18 6.1 Specification ....................
-
Page 4: Declarations
RGBlink. If the purchaser or a third party carries out modifications or repairs on goods delivered by RGBlink, or if the goods are handled incorrectly, in particular if the systems are commissioned operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid. -
Page 5: Operators Safety Summary
To avoid explosion, do not operate this product in an explosive atmosphere. Installation Safety Summary Safety Precautions For all MSP 214 processor installation procedures, please observe the following important safety and handling rules to avoid damage to yourself and the equipment. MSP214... - Page 6 Site Preparation The environment in which you install your MSP 214 should be clean, properly lit, free from static, and have adequate power, ventilation, and space for all components.
-
Page 7: Chapter 1 Your Product
Chapter 1 Your Product 1.1 In the Box AC Power Cord Note: AC Power Cable supplied as standard according to destination market. MSP214 User Manual... -
Page 8: Product Overview
MSP 214 DVI to Fiber is the transmitter, and MSP 214 Fiber to DVI is the receiver, the two devices are used together, it can be realized the long distance transmission of DVI signal by MSP 214 DVI to Fiber with fiber optical cable to MSP 214 Fiber to DVI. -
Page 9: Msp 214 Dvi To Fiber Panel
1.2.1 MSP 214 DVI to Fiber Panel DVI Input and Signal Indicator DVI Input Used to input DVI from DVI player or computer with DVI connector. (DVI is compatible with HDMI) Signal Indicator When input DVI signal, the signal indicator lights. - Page 10 Indicator Indicator Power indicator 2 lights when device has power supply. Indicator LED indicator 5 is off when connect fiber cable and the device is in normal operation. Fiber Output Fiber Output Used to connect fiber cable, the device uses single-mode twin-core fiber or multi-mode twin-core fiber, LC interface.
-
Page 11: Msp 214 Fiber Panel To Dvi
1.2.2 MSP 214 Fiber Panel to DVI Power Power Connect one end of the power adapter with the device, the other end into a socket. Plug in, red power indicator light means the device works normally. The device uses the standard 12V/3A power supply. - Page 12 Fiber Input Fiber Input Used to connect fiber cable, the device uses single mode twin-core fiber or multi-mode twin-core fiber, LC interface. UART UART Connect PC and UART by USB convert RS232 convert TRS(3.5mm audio interface) to update. Please disconnect the power before upgrade. The upgrade firmware have Local EDID version and straight EDID version.
-
Page 13: Dimension
1.2.3 Dimension Following is the dimension of MSP 214 for your reference: MSP214 User Manual... -
Page 14: Chapter 2 Installing Your Product
MSP 214 DVI to Fiber transmitter is connected to computer, media player or HD camera, etc. User can connect the DVI interface on MSP 214 DVI to Fiber panel to PC with DVI cable, then connect the computer or media player, and MSP 214 DVI to Fiber transmitter to power supply. -
Page 15: Msp 214 Fiber To Dvi
Connect the fiber interface to the other fiber interface on MSP 214 DVI to Fiber transmitter with fiber cable, and then connect the DVI interface on MSP 214 Fiber to DVI panel to display device. After the connection, the EQ Balance starts automatically on the MSP 214 Fiber to DVI receiver. -
Page 16: Chapter 3 Questions And Troubleshoot
Chapter 3 Questions and Troubleshoot 3.1 Power indicator light is off or blinks 1. Check whether plug in the power cord, and has power supply; 2. Check whether the power cable is connected, and in good connection; 3. If above without problem, then the power indicator is damaged. 3.2 Signal indicator light is off or blinks 1. -
Page 17: Chapter 4 Ordering Codes
Chapter 4 Ordering Codes 4.1 Product 611-0214-01-1 MSP 214 MSP214 User Manual... -
Page 18: Chapter 5 Technical Support
Chapter 5 Technical Support 5.1 Contact Us MSP214 User Manual... -
Page 19: Chapter 6 Appendix
Chapter 6 Appendix 6.1 Specification DVI Input Number of Inputs Connector Standard DVI-I socket Supported Resolution VESA： 800×600@60 | 1024×768@60 | 1280×768@60 | 1280×1024@60 | 1360×768@60 | 1366×768@60 | 1400×1050@60 | 1440×900@60 | 1600×1200@60 | 1680×1050@60 | 1920×1080@60 | 1920×1200@60 | 2048×1152@60 | 2560×812@60 | 2560×816@60 | 3840×2160@30 STMPE：... - Page 20 Transmission Distance 10km Transmission Single-mode twin-core Hot Plug Support 10 Gigabit multi-mode 300m optical fiber module Wavelength of Light 1270nm Transmission Transmission Rate 10G bps Transmission Distance 300m Transmission Multi-mode twin-core Hot Plug Support Extras Power Supply 12V DC/3A Working Environment 0℃~45℃...
-
Page 21: Terms & Definitions
Chapter 6: Appendix 6.2 Terms & Definitions The following terms and definitions are used throughout this guide. “ASCII”: American Standard for Information Interchange. The standard code consisting of 7-bit coded characters (8 bits including parity check) used to exchange information between data processing systems, data communication systems, and associated equipment. - Page 22 Chapter 6: Appendix “Contrast ratio”: The radio of the high light output level divided by the low light output level. In theory, the contrast radio of the television system should be at least 100:1, if not 300:1. In reality, there are several limitations. In the CRT, light from adjacent elements contaminate the area of each element.
- Page 23 Chapter 6: Appendix CD-quality audio, and control data at CD-ROM bandwidth. The MPEG algorithm provides inter-frame compression of video images and can have an effective compression rate of 100:1 to 200:1. “NTSC”: The color video standard used in North America and some other parts of the world created by the National Television Standards Committee in the 1950s.
- Page 24 Chapter 6: Appendix “SDI”: Serial Digital Interface. The standard based on a 270 Mbps transfer rate. This is a 10-bit, scrambled, polarity independent interface with common scrambling for both component ITU-R 601 and composite digital video and four channels of (embedded) digital audio.
-
Page 25: Reversion And History
6.3 Reversion and History The table below lists the changes to the Video Processor User Manual. Format Time ECO# Description Principal 2010-11-15 0000 Release LISA 2013-08-07 0001 Change the integral style of product Vira and user manual. 2014-01-20 0002 1. Update Shenzhen office address. Vira 2.
