- Page 1 ASK plus 4K Wireless HDMI Extender User Manual Article No: RGB-RD-UM-ASK plus E002 Revision No: V1.2...
-
Page 2: Table Of Contents
Content Declarations ..........................2 FCC/Warranty ..........................2 Operators Safety Summary ......................3 Installation Safety Summary ......................3 Chapter 1 Your Product ......................5 1.1 In the Box ..........................5 1.2 Product Overview ........................5 1.2.1 Key Features ........................5 1.2.2 Interface ..........................6 1.2.3 Dimensions ........................7 Chapter 2 Use Your Product ...................... -
Page 3: Declarations
30 days after the transfer of risks. In the event of justified notice of compliant, RGBlink can repair the fault or provide a replacement at its own discretion within an appropriate period. If this measure proves to be impossible or unsuccessful, the purchaser can demand a reduction in the purchase price or cancellation of the contract. -
Page 4: Operators Safety Summary
Operators Safety Summary The general safety information in this summary is for operating personnel. Do Not Remove Covers or Panels There are no user-serviceable parts within the unit. Removal of the top cover will expose dangerous voltages. To avoid personal injury, do not remove the top cover. Do not operate the unit without the cover installed. - Page 5 wire provided in the AC power Cord. The AC Socket-outlet should be installed near the equipment and be easily accessible. Unpacking and Inspection Before opening device shipping box, inspect it for damage. If you find any damage, notify the shipping carrier immediately for all claims adjustments. As you open the box, compare its contents against the packing slip.
-
Page 6: Chapter 1 Your Product
3 * 5V 2A USB Power Adapter 1 * micro USB Cable 1.2 Product Overview ASK plus, 4K wireless HDMI extender, supports 4K60 resolution, super smooth playback with 100ms low latency. This versatile extender supports wireless transmitter with two receivers without latency, which allows users to wireless stream the video content from one transmitter to two receivers simultaneously, excellent for applications like education or digital signage. -
Page 7: Interface
● Touch panel back control function ● Auto channel selection ● Equipped with the fast 802. 11ac 2T2R WiFi MIMO module ● High-security protection ● Supports one transmitter to multiple receivers ● Transmission distance up to 150 meters in the clear line of sight for 1*RX, and 50 meters for 2*RX 1.2.2 Interface Transmitter... -
Page 8: Dimensions
IR Window IR extended function（to be developed） ● Flashing Blue: Waiting for connection LED In di ca tor ● Static Blue: Connected 1.2.3 Dimensions Following is the dimension of ASK plus (TX/RX) for your reference: Dimension: 154.0mm x 77.5mm x 21.0mm... -
Page 9: Chapter 2 Use Your Product
Chapter 2 Use Your Product 2.1 Pairing of TX and RX Before delivery, each ASK plus set has been paired , but when extra RX is required, following steps are the methods for users to finish TX/RX pairing. 1）Power on the transmitter；... -
Page 10: Connecting The Receiver
2.2.2 Connecting the Receiver 1) Connect the power adapter to the connector marked "5V DC" and insert the plug into the wall socket； 2) Place the receiver in the room where you want to connect the second TV or projector； 3) Use an HDMI cable to connect TV or projector to the HDMI port marked “HDMI OUT”... -
Page 11: Testing The Usb Extension Function
2.4 Testing the USB Extension Function Once users have connected the Micro USB cable and mouse/keyboard according to the above description, it is recommended to test the function first. 1）Take a mouse or keyboard and use one of the functions； 2）The receiver will now send this function to the transmitter；... -
Page 12: Chapter 3 Order Codes
Chapter 3 Order Codes Product Code Item 450-3002-02-0 ASK plus 4K Wireless HDMI Extender (1*TX + 2*RX）... -
Page 13: Chapter 4 Support
Chapter 4 Support 4.1 Contact us... -
Page 14: Chapter 5 Appendix
3) Disconnect the power adapters from the wall socket and reconnect them to reboot the 4K wireless HDMI extender. 3. I do have picture, but no (or bad) sound. ASK plus supports up to 2CH PCM stereo. -
Page 15: Specification
Check the audio setting in the settings menu of the connected HDMI source and manually set it to 2CH PCM stereo when the automatic setting does not work. 5.2 Specification Interface Input HDMI 1×HDMI -A Output HDMI 1×HDMI-A HDMI 1×HDMI-A Control 1×Micro-USB (PC) 1×IR (to be developed) - Page 16 ●BNC: Stands for Bayonet Neill-Concelman. A cable connector used extensively in television (named for its inventors). A cylindrical bayonet connector that operates with a twist-locking motion. ●CVBS: CVBS or Composite video, is an analog video signal without audio. Most commonly CVBS is used for transmission of standard definition signals.
- Page 17 ●HDMI 1.4 : released on June 5, 2009, added support for 4096 × 2160 at 24 Hz, 3840 × 2160 at 24, 25, and 30 Hz, and 1920 × 1080 at 120 Hz. Compared to HDMI 1.3, 3 more features added which are HDMI Ethernet Channel (HEC) , audio return channel (ARC),3D Over HDMI, a new Micro HDMI Connector, an expanded set of color spaces.
- Page 18 ●SFP: Small form-factor pluggable, is a compact, hot-pluggable network interface module used for both telecommunication and data communications applications. ●Optical Fiber Connector: Terminates the end of an optical fiber, and enables quicker connection and disconnection than splicing. The connectors mechanically couple and align the cores of fibers so light can pass.
- Page 19 USB 3.0 USB 3.1&3.2 ●NTSC: The colour video standard used in North America and some other parts of the world created by the National Television Standards Committee in the 1950s. NTSC utilizes an interlaced video signals. ●PAL: Phase Alternate Line. A television standard in which the phase of the colour carrier is alternated from line to line.
- Page 20 specification includes support for digital video. ●NDI: Network Device interface (NDI) is a software standard developed by NewTek to enable video-compatible products to communicate, deliver, and receive broadcast quality video in a high quality, low latency manner that is frame-accurate and suitable for switching in a live production environment over TCP (UDP) Ethernet based networks.
- Page 21 ●OSC: The principle of Open Sound Control (OSC) protocol is for networking sound synthesizers, computers, and multimedia devices for musical performance or show control. As with XML and JSON, the OSC protocol allows sharing data. OSC is transported via UDP packets between devices connected on an Ethernet.
- Page 22 bars are two rows of reversed colour bars ●Seamless Switching: A feature found on many video switchers. This feature causes the switcher to wait until the vertical interval to switch. This avoids a glitch (temporary scrambling) which often is seen when switching between sources. ●Scaling: A conversion of a video or computer graphic signal from a starting resolution to a new resolution.
-
Page 23: Revision History
Aster standard in Specification. All information herein is Xiamen RGBlink Science & Technology Co Ltd. excepting noted. is a registered trademark of Xiamen RGBlink Science & Technology Co Ltd. While all efforts are made for accuracy at time of printing, we reserve the right to alter...
