Summary of Contents for Elation TVL551
- Page 1 TVL SOFTLIGHT DW™ user manual...
- Page 2 +31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | info@elationlighting.eu Elation Professional Mexico | AV Santa Ana 30 | Parque Industrial Lerma, Lerma, Mexico 52000 +52 (728) 282-7070 D O C U M E N T V E R S I O N...
-
Page 3: Table Of Contents
C O N T E N T S General Information Warranty Safety Instructions and Guidelines Fixture Overview Barn Door Installation Fixture Installation Fixture Menu DMX Channel Functions And Values Cleaning and Maintenance Technical Specifications Optional Accessories... -
Page 4: General Information
G E N E R A L I N F O R M A T I O N INTRODUCTION This fixture has been designed to perform reliably for years when the guidelines in this booklet are followed. Please read and understand the instructions in this manual carefully and thoroughly before attempting to operate this unit. - Page 5 You may also visit us on the web at www.elationlighting.com for any comments or suggestions. For service related issue please contact Elation Professional®. ELATION SERVICE USA - Monday - Friday 8:00am to 5:00pm PST Voice: 323-582-3322 Fax: 323-832-9142 E-mail: support@elationlighting.com...
-
Page 6: Warranty
Elation Professional® hereby warrants, to the original purchaser, Elation Professional® products to be free of manufacturing defects in material and workmanship for a period of two years (730 days), and Elation Professional® product rechargeable batteries to be free of manufacturing defects in material and workmanship for a period of six months (180 days), from the original date of purchase. -
Page 7: Safety Instructions And Guidelines
S A F E T Y I N S T R U C T I O N S A N D G U I D E L I N E S This fixture is an extremely sophisticated piece of electronic equipment. To guarantee a smooth operation, it is important to follow all instructions and guidelines in this manual. - Page 8 S A F E T Y I N S T R U C T I O N S A N D G U I D E L I N E S • DO NOT TOUCH the fixture housing during operation. Turn OFF the power and allow approximately 15 minutes for the fixture to cool down before serving.
-
Page 9: Fixture Overview
F I X T U R E O V E R V I E W LCD Menu Function Display MENU, UP, DOWN, ENTER Buttons DIMMER Dial (manual control) COLOR TEMPERATURE DIAL (manual control) IP65 Locking Power Connector IN FUSE (T2A) BATTERY Connection - NOT SUPPORTED AT THIS TIME 5pin DMX IN/OUT Ethernet (RJ45) IN... -
Page 10: Barn Door Installation
B A R N D O O R I N S T A L L A T I O N 1. Remove barn door from packaging. 2. Open barn door fully and position in front of the fixture. 3. Align each of the (4) mounting screws by pushing them into place. 4. -
Page 11: Fixture Installation
F I X T U R E I N S T A L L A T I O N F L A M M A B L E M A T E R I A L W A R N I N G Keep fixture at least 5.0 ft (1.5m) away from any flammable materials, decorations, pyrotechnics, etc. - Page 12 MOUNTING POINTS Overhead mounting requires extensive experience, including amongst others calculating working load limits, installation material being used, and periodic safety inspection of all installation material and the device. If you lack these qualifications, do not attempt the installation yourself. Improper installation can result in bodily injury. Fixture is fully operational in the specific mounting positions as illustrated below.
- Page 13 CLAMP MOUNTING The fixture includes an adjustable mounting yoke that attaches to both sides of the fixture. When mounting this fixture to truss be sure to secure an appropriately rated clamp to the mounting yoke using a M10 screw fitted through the center hole of the mounting yoke. Be sure to attach a Safety Cable to the fixture using the safety cable rigging point on the back of the fixture as illustrated below.
-
Page 14: Fixture Menu
F I X T U R E M E N U ON-BOARD SYSTEM MENU The fixture comes with an easy to navigate system menu. The next section will detail the functions of each command in the system menu. LCD MENU CONTROL PANEL The control panel (see image below) located on back of the fixture allows you to access the main menu and make all necessary adjustments to the fixture. - Page 15 ELATION TVL SOFTLIGHT DW™ S Y S T E M M E N U Supports Software Versions: ≥ V1.1 Features subject to change without any prior written notice. SUB MENU OPTIONS / VALUES DESCRIPTION MAIN MENU (Default Settings in BOLD)
- Page 17 SYSTEM MENU CHANGE WITH SOFTWARE UPDATE VERSION 1.6 See highlighted menu items below which have been updated with this software update. ELATION TVL SOFTLIGHT DW™ S Y S T E M M E N U Supports Software Versions: ≥ V1.6 Features subject to change without any prior written notice.
-
Page 18: Dmx Channel Functions And Values
D M X C H A N N E L F U N C T I O N S A N D V A L U E S ELATION© TVL SOFTLIGHT DW™ DMX Channel Values / Functions (7 Total DMX Channels) Supports Software Versions ≥: V1.0... -
Page 19: Cleaning And Maintenance
Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized Elation service technician. Should you need any spare parts, please order genuine parts from your local Elation dealer. -
Page 20: Technical Specifications
T E C H N I C A L S P E C I F I C A T I O N S SOURCE 240 Cool White + 240 Warm White LEDs 20,000 Hour Average LED Life* *May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming. - Page 21 DIMENSIONAL DRAWINGS Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice.
-
Page 22: Optional Accessories
O P T I O N A L A C C E S S O R I E S ORDER CODE ITEM TVL562 SNAPGRID 40° Light Control Grid NARROW CLAMP Heavy Duty Wrap Around Clamp AC5PDMX5PRO 5 ft. (1.5m) 5pin PRO DMX Cable CAT005 5' (1.5m) CAT6 Ethernet Cable Additional Cable Lengths Available...
