- Page 1 DTW BLINDER 350 IP™ user manual ...
- Page 2 Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040 323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com Elation Professional B.V.
-
Page 3: Table Of Contents
. e l a t i o n l i g h t i n g . c o m C O N T E N T S General Information Warranty Safety Instructions and Guidelines Overview Installation System Menu DMX Channel Functions And Values Cleaning and Maintenance Technical Specifications Optional Accessories DTW BLINDER 350 IP™ User Manual... -
Page 4: General Information
O P T I O N A L C O R R O S I O N - R E S I S T A N T C O A T I N G Optional Corrosion-Resistant Coatings may be available for this fixture. Please consult your Elation Professional sales representative for details. DTW BLINDER 350 IP™ User Manual... - Page 5 You may also visit us on the web at www.elationlighting.com any comments or suggestions. For service related issue please contact Elation Professional®. ELATION SERVICE USA - Monday - Friday 8:00am to 5:00pm PST...
- Page 6 Damages resulting from modifications to this fixture and/or the disregard of safety and general user instructions found in this user manual void the manufactures warranty and are not subject to any warranty claims and/or repairs. DTW BLINDER 350 IP™ User Manual...
-
Page 7: Warranty
No accessories should be shipped with the product. If any accessories are shipped with the product, Elation Professional® shall have no liability what so ever for loss and/or or damage to any such accessories, nor for the safe return thereof. -
Page 8: Safety Instructions And Guidelines
RETINA INJURY RISK - MAY INDUCE BLINDNESS! SENSITIVE PERSONS MAY SUFFER AN EPILEPTIC SHOCK! ENSURE ALL CONNECTIONS AND END CAPS ARE PROPERLY SEALED WITH A DIELECTRIC GREASE (AVAILABLE AT MOST ELECTRICAL SUPPLIERS) TO PREVENT WATER CORROSION AND/OR ELECTRICAL SHORT CIRCUIT. DTW BLINDER 350 IP™ User Manual... - Page 9 Consistent operational breaks will ensure the fixture will function properly for many years to come. Use the original packaging and materials to transport the fixture in for service. DTW BLINDER 350 IP™ User Manual...
-
Page 10: Overview
. e l a t i o n l i g h t i n g . c o m O V E R V I E W SAFETY CABLE RIGGING POINTS DTW BLINDER 350 IP™ User Manual... -
Page 11: Installation
10 times the weight of the fixture. Fixture installation must always be secured with a secondary safety attachment, such as an appropriate safety cable. Never stand directly below the device when mounting, removing or servicing. DTW BLINDER 350 IP™ User Manual... - Page 12 S A F E T Y C A B L E ALWAYS USE A SAFETY CABLE WHENEVER INSTALLING THIS FIXTURE IN A SUSPENDED ENVIRONMENT TO ENSURE THE FIXTURE WILL NOT DROP IF THE CLAMP FAILS. DTW BLINDER 350 IP™ User Manual...
- Page 13 ¼ turn, until both small black raised plastic tabs are positioned vertical at 12 and 6 o’clock. (See image below) ENSURE ALL LEN FILTERS ARE SECURELY INSTALLED AS ILLUSTRATED ABOVE BEFORE THE FIXTURE IS INSTALLED ON TRUSS AND/OR RIGGING. DTW BLINDER 350 IP™ User Manual...
- Page 14 Max number of DTW BLINDER 350 IP™ units power linked together: 3 units @120V | 6 units @240V NOTE: USE CAUTION WHEN POWER LINKING OTHER FIXTURES TO DTW BLINDER 350 IP™! POWER CONSUMPTION OF OTHER LIGHTING FIXTURES WILL VARY! ALWAYS CHECK MAX AMP OUT RATING PRINTED ON THE REAR CONNECTION PANEL!
-
Page 15: System Menu
4. Press UP, then the display will change to: LOCKED** (three * disappear) 5. Press DOWN, then the display will change to: LOCKED* (4 * disappear) 6. Press ENTER, then the display will change to LOCKED and then become unlocked. DTW BLINDER 350 IP™ User Manual... - Page 16 Set GAMMA Brightness Value TempUnit F, °C Temperat XXX F° / C° Displays Temperature of LED #1 SYSTEM TEMP XXX F° / C° Displays Temperature of LED #2 Default OFF / ON Restore Factory Settings DTW BLINDER 350 IP™ User Manual...
- Page 17 . e l a t i o n l i g h t i n g . c o m DIMMER Select desired DIMMER MODE (Standard, Stage, TV, Architectural, Theatre). DTW BLINDER 350 IP™ User Manual...
-
Page 18: Dmx Channel Functions And Values
LEDs ON MASTER DIMMER 0-255 0 to 100% MASTER DIMMER FINE (16 bit) 0-255 0 to 100% DIMMING CURVE MODES 0-20 STANDARD 21-40 STAGE 41-60 61-80 ARCHITECTURAL 81-100 THEATRE 101-255 Default to Unit Setting DTW BLINDER 350 IP™ User Manual... -
Page 19: Cleaning And Maintenance
Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized Elation service technician. Should you need any spare parts, please order genuine parts from your local Elation dealer. -
Page 20: Technical Specifications
5F to 113°F (-15°C to 45°C) APPROVALS / RATINGS CE | RoHs | IP65 Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. DTW BLINDER 350 IP™ User Manual... - Page 21 78° Beam Diameter No Fresnel Lens 9.8 ft 13.1 ft 16.4 ft 78° Beam 4.99 16.4 6.67 21.9 8.21 26.9 Diameter WW LEDs 3,100K AMBER LEDS 1,400K FULL ON 2,940K DTW BLINDER 350 IP™ User Manual...
-
Page 22: Dimensional Drawings
. e l a t i o n l i g h t i n g . c o m DIMENSIONAL DRAWINGS Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. DTW BLINDER 350 IP™ User Manual... -
Page 23: Optional Accessories
O P T I O N A L A C C E S S O R I E S ORDER CODE ITEM TRIGGER CLAMP Heavy Duty Wrap Around Clamp 8050000053 Omega Bracket (107mm) NEU088 3 ft. (1m) PowerCON TRUE1 Power Link Cable Additional Cable Lengths Available DTW BLINDER 350 IP™ User Manual...
