SOFTWARE SETUP
9. Configure the Serial Monitor to allow communication to the DC2026 through USB. On the bottom of the Serial
Monitor window, set the following starting from bottom left to bottom right:
a. Click on the Autoscroll checkbox for the ✓ check mark symbol.
b. Select Both NL & CR on the left dropdown menu.
c. Select 115200 baud on the right dropdown menu.
d. As shown in Figure 11, when configured correctly the DC2515 sketch menu will appear.
10
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Figure 11. DC2515 Sketch Menu
