Anybus X-gateway PROFIBUS Master Interface

4.3. Network Configuration Example

In this example a simple PROFIBUS network has been created using the free Windows-based network
configuration tool Anybus NetTool for PROFIBUS. The network consists of 3 slaves and an Anybus X-gateway
PROFIBUS Master Interface acting as master.
Figure 5. Example network in Anybus NetTool for PROFIBUS
Node Slot
0 (master)
1
3
2
4 1
1
5
2
The slave I/O addresses overview window in NetTool shows the resulting slave I/O map:
Figure 6. Slave address overview in Anybus NetTool
Node Input address range
3 0... 127
4 -
5 128... 159
Note that the actual input/output addresses defined in the I/O map are the ones that will be used on the other
end.
Page 8 of 10
Input data size
128 bytes
32 bytes
Output address range
0... 127 128... 159
160... 191
192... 255
Network Configuration Example
Output data size
128 bytes
32 bytes
32 bytes
64 bytes
