Anybus X-gateway PROFIBUS Master Interface

5. Technical Data

5.1. Technical Specifications

PROFIBUS functionality
Maximum number of slaves
Maximum I/O data
Supported baud rates
Configuration method
PROFIBUS connector
Configuration port
Page 10 of 10
• Complete Profibus DP Master functionality according to IEC 61158
• Optional Live List of the active status of the connected slaves
125
512 bytes in each direction
Automatic baudrate detection up to 12 Mbit/s
Anybus Configuration Manager via serial port (RS-232)
1 x D-sub 9-pin female
1 x D-sub 9-pin male
Technical Data
SCM-1202-104 Version 1.1
