- Page 1 All manuals and user guides at all-guides.com Официальный представитель: ООО «СпортРус» 117105, Российская Федерация, г.Москва, Варшавское шоссе, д.33 Телефон: (495) 276 27 26, 221 26 29 www.aerofit.ru MTH-1100 OWNER'S MANUAL...
- Page 2 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS HARDWARE ILLUSTRATION (A1)HEX BOLT 1/2"x1-1/4"L PARTIAL THREAD QTY.2 (A2)HEX BOLT 1/2"x2-1/4"L PARTIAL THREAD QTY.3 (A3)HEX BOLT 3/8"x5"L PARTIAL THREAD QTY.2 (A4)ROUND ALLEN HEAD 5/16""x1-1/4"L PARTIAL THREAD QTY.4 (A5)HEX BOLT 5/16"x2-3/4"L PARTIAL THREAD QTY.2 (A6)HEX BOLT 5/16"x3"L PARTIAL THREAD QTY.2 (A13)HEX BOLT M8X30L PARTIAL THREAD(8260-057) QTY.2 inch...
- Page 3 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS FRAME HARDWARE ILLUSTRATION (A7)HEX BOLT 1/2"x2-3/4"L PARTIAL THREAD QTY.3 (A8)ROUND ALLEN HEAD 3/8"x2"L PARTIAL THREAD QTY.1 (A9)ROUND ALLEN HEAD M10X40L PARTIAL THREAD QTY.1 (A10)ROUND ALLEN HEAD M6X16L PARTIAL THREAD QTY.16 inch 6"...
- Page 4 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS FRAME HARDWARE ILLUSTRATION FOR MDAA (A11)ELASTIC BELT (F920003) QTY.1 (A12)10LB PIN (8250-128) QTY.1 inch 6" 1" 2" 3" 4" 5" MTH1100-072010 Page...
- Page 5 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS HARDWARE ILLUSTRATION (B1)NYLON LOCK NUT 1/2"X8H QTY.2 (C2)1/2"(I.D.)FLAT WASHER Ø34 QTY.3 (B2)NYLON LOCK NUT 1/2" QTY.2 (C3)3/8"(I.D.)ARC WASHER R30 QTY.4 (B3)NYLON LOCK NUT 3/8" QTY.2 (C4)5/16" SPRING WASHER QTY.4 (B4)NYLON LOCK NUT M8 QTY.2 (C5)5/16"(I.D.)FLAT WASHER Ø24 QTY.4 (C1)1/2"(I.D.)FLAT WASHER Ø25 QTY.6 inch...
- Page 6 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS FRAME HARDWARE ILLUSTRATION (C10)M6 (I.D.)FLAT WASHER Ø19 QTY.16 (B5)NYLON LOCK NUT 1/2" QTY.3 (B6)NYLON LOCK NUT M10 QTY.1 (C6)1/2"(I.D.)FLAT WASHER Ø25 QTY.2 (C7)1/2"(I.D.)FLAT WASHER Ø34 QTY.4 (C8)3/8" SPRING WASHER QTY.1 (C9)M10(I.D.)FLAT WASHER Ø19 QTY.2 inch 1"...
- Page 7 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS HARDWARE ILLUSTRATION D1.Ø60 CAP COVER(8130-231)---------------------------------[2PCS] D2.Ø10X60L SHAFT (8210-156) --------------------------------[1PCS] D3.ROLLER THRUST BEARING(8510-008)------------------[2PCS] D4.Ø1" CU WASHER(8520-008)---------------------------------[6PCS] D5.Ø50 END CAP(9211-074)--------------------------------------[6PCS] D6. o 50X50X1.8T End Cap (9211-087)------------------------[3PCS] D7.Ø28 PLUG(9211-095)------------------------------------------[4PCS] D8.58X116 END CAP(9211-112)---------------------------------[1PCS] D9. Ø27.5X12.5L Rubber Pad(9214-030)----------------------[4PCS] D10.95X140 RUBBER PAD(9310-035)-------------------------[4PCS] D11.108X263 RUBBER PAD(9310-075)------------------------[1PCS] D12.
- Page 8 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS HARDWARE ILLUSTRATION D14.4350mm BELT(FMTH1100)-----------------------------------[1PCS] D15.EXERCISE CHART (9420-066)------------------------------[1PCS] D16.EXERCISE CHART (9420-069)------------------------------[1PCS] MTH1100-072010 Page...
- Page 9 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS FRAME HARDWARE ILLUSTRATION D17.3/4" SHAFT COLLAR(9211-147)-----------------------------------[2PCS] D18.Ø4" RUBBER PAD(9310-017)--------------------------------------[2PCS] D19.108X263 RUBBER PAD(9310-075)-------------------------------[2PCS] D20. n 115 PULLEY(9213-042A)------------------------------------------[1PCS] D21. n 115 PULLEY(9213-042B)------------------------------------------[2PCS] D22.BOTTLE BRACKET(8388-025)-------------------------------------[1PCS] D23.BOTTLE RACK(9260086-019)--------------------------------------[1PCS] D24.BOTTLE(9260-123)----------------------------------------------------[1PCS] no magnet magnet MTH1100-072010 Page...
- Page 10 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS FRAME HARDWARE ILLUSTRATION D25.TOP PLATE(8400-019)---------------------------------------------[1PCS] D26.Selector Rod(8210-042C)------------------------------------------[1PCS] MTH1100-072010 Page...
- Page 11 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS PARTS ILLUSTRATION SHEET A[1PCS] B[1PCS] C[1PCS] E[1PCS] D[1PCS] F[1PCS] G[1PCS] H[1PCS] Direction Direction I[1PCS] K[1PCS] L[1PCS] 163.5 MTH1100-072010 Page...
- Page 12 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS PARTS ILLUSTRATION SHEET O[2PCS] M[2PCS] N[1PCS] 8220-196 8240-098 Ø25X356L 25° Q[1PCS] P[1PCS] 8311-117 8313-144 60X25X6T 95X6TX250L T[2PCS] U[2PCS] R[1PCS] S[1PCS] 9131-041 8110-113 9111-069 9121-083 Ø35xØ25.2x133L MTH1100-072010 Page...
- Page 13 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS FRAME PARTS ILLUSTRATION SHEET J[1PCS] AA[1PCS] 2255027 AB[1PCS] AC[1PCS] 9220-017 9220-018 AE[1PCS] AD[1PCS] 9211-148 9220-023 MTH1100-072010 Page...
- Page 14 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS FRAME PARTS ILLUSTRATION SHEET AG[1PCS] AF[4PCS] AH[1PCS] 8313-169 8331-057 8311-117 133.5 AJ[2PCS] AI[3PCS] 8313-144 8331-058 98.8 AK[1PCS] AL[2PCS] 6640-015 5313-R001 Ø3/4"X1243L AN[2PCS] AO[1PCS] AM[1PCS] 8311-119 8311-120 8331-056 53.5 MTH1100-072010 Page...
- Page 15 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS Above shows STEP 1 assembled and completed A10x2 C10x2 A10x2 C10x2 M10X25L CONE SCREW A10x6 C10x6 6640-011 CU WASHER(8520-008) CU WASHER(8520-008) Ø60 CAP COVER(8130-231) M10X25L CONE SCREW X4 MTH1100-072010 Page...
- Page 16 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS Above shows STEP 2 assembled and completed 1/2"X1-1/4" HEX BOLT X2 1/2" WASHER Ø25 X2 1/2"X1-1/4"L HEX BOLT X2 1/2" WASHER Ø34 X2 1/2" WASHER Ø25 X2 1/2"X1"L HEX BOLT X2 1/2"X1-1/4"L HEX BOLT X2 M10X25L CONE SCREW X4 1/2"...
- Page 17 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS Above shows STEP 3 assembled and completed Ø25X356L shaft(8220-19) short long long edge long edge MTH1100-072010 Page...
- Page 18 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS The terminal surface needs to be parallel Above shows STEP 4 assembled and completed Attention *:NEED TO LOOSEH BOTH ALLEN HEAD BOLT IN ORDER TO REMOVE PART#(L) B2 C1 D10x2 D10x2 D5x2 D5x2...
- Page 19 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS Above shows STEP 5 assembled and completed B3x2 D4x2 D1x2 M10X25L CONE SCREW X2 MTH1100-072010 Page...
- Page 20 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS The belt should reserve 40mm extra length M10X25L RIOUND BOLT X2 M10 SPRING WASHER X2 Above shows STEP 6 assembled and completed The tread side should be outward Figure 1 M10X25L CONE SCREW Ø60 CAP COVER(8130-231) *ATTENTION*...
- Page 21 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS NOTE: 1. THE BELT SMOOTH SIDE SHOULD ATTACH ON PULLEY SURFACE, AND THE BELT SMOOTH SIDE WRAP AROUND THE BELT RETAINER SHAFT (AH) 2. PLEASE BE SURE THE PRESSURE BETWEEN THE BELT CLAMPS (AG) DO Above shows STEP 7 NOT EXCEED 70 PSI assembled and completed...
- Page 22 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS NOTE: 1. THE BELT SMOOTH SIDE SHOULD ATTACH ON PULLEY SURFACE, AND THE BELT SMOOTH SIDE WRAP AROUND THE BELT RETAINER SHAFT (AH) 2. PLEASE BE SURE THE PRESSURE Above shows STEP 8 BETWEEN THE BELT CLAMPS (AG) DO assembled and completed NOT EXCEED 70 PSI...
- Page 23 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS Material detail drawing of line 9542-145-LINE JST-XHP-9 JST-XHP-9 1700 BLACK BLACK PLAM PLAM ORANGE ORANGE YELLOW YELLOW GREEN GREEN BLUE BLUE PURPLE PURPLE GREY GREY 9542-148-LINE JST-XHP-3 JST-SMP-03V-BC A:HOLE COLOR B:HOLE COLOR BLACK BLACK PALM...
- Page 24 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS Material detail drawing of line 9545-034-LINE JST-SMR-03V-B MTH1100-072010 16.2 Page...
- Page 25 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS 9542-145-line link AK 9542-148-line link 9545-034 Above shows STEP 9 assembled and completed Figure 4 9542-145-Line 9542-148-Line M4X12L ROUND ALLEN CROSS BOLT X2 LINK AA LINK D22 LINK AA M4X12L ROUND ALLEN CROSS BOLT X4 M6X12L ROUND BOLT X5 M6 WASHER Ø14X4...
- Page 26 All manuals and user guides at all-guides.com MTH-1100 ASSEMBLY INSTRUCTIONS M10X12L ROUND BOLT X4 Above shows STEP 10 assembled and completed EXTRUDING EXTRUDING Figure 5 Note: When installing the shroud (AD), push both sides of the shroud toward center in order to bend it a little. After insert it to the door frame and then releasing it.
