Page 17
MTH-1100 ASSEMBLY INSTRUCTIONS Above shows STEP 3 assembled and completed Ø25X356L shaft(8220-19) short long long edge long edge MTH1100-072010 Page...
Page 18
MTH-1100 ASSEMBLY INSTRUCTIONS The terminal surface needs to be parallel Above shows STEP 4 assembled and completed Attention *:NEED TO LOOSEH BOTH ALLEN HEAD BOLT IN ORDER TO REMOVE PART#(L) B2 C1 D10x2 D10x2 D5x2 D5x2 D5x2 MTH1100-072010 Page...
Page 20
MTH-1100 ASSEMBLY INSTRUCTIONS The belt should reserve 40mm extra length M10X25L RIOUND BOLT X2 M10 SPRING WASHER X2 Above shows STEP 6 assembled and completed The tread side should be outward Figure 1 M10X25L CONE SCREW Ø60 CAP COVER(8130-231) *ATTENTION* Do not touch the sensor CU WASHER(8520-008) bracket (AK) during weight...
Page 21
MTH-1100 ASSEMBLY INSTRUCTIONS NOTE: 1. THE BELT SMOOTH SIDE SHOULD ATTACH ON PULLEY SURFACE, AND THE BELT SMOOTH SIDE WRAP AROUND THE BELT RETAINER SHAFT (AH) 2. PLEASE BE SURE THE PRESSURE BETWEEN THE BELT CLAMPS (AG) DO Above shows STEP 7 NOT EXCEED 70 PSI assembled and completed Assemble...
Page 22
MTH-1100 ASSEMBLY INSTRUCTIONS NOTE: 1. THE BELT SMOOTH SIDE SHOULD ATTACH ON PULLEY SURFACE, AND THE BELT SMOOTH SIDE WRAP AROUND THE BELT RETAINER SHAFT (AH) 2. PLEASE BE SURE THE PRESSURE Above shows STEP 8 BETWEEN THE BELT CLAMPS (AG) DO assembled and completed NOT EXCEED 70 PSI The tread side should be outward...
Page 23
MTH-1100 ASSEMBLY INSTRUCTIONS Material detail drawing of line 9542-145-LINE JST-XHP-9 JST-XHP-9 1700 BLACK BLACK PLAM PLAM ORANGE ORANGE YELLOW YELLOW GREEN GREEN BLUE BLUE PURPLE PURPLE GREY GREY 9542-148-LINE JST-XHP-3 JST-SMP-03V-BC A:HOLE COLOR B:HOLE COLOR BLACK BLACK PALM PLAM MTH1100-072010 16.1 Page...
Page 24
MTH-1100 ASSEMBLY INSTRUCTIONS Material detail drawing of line 9545-034-LINE JST-SMR-03V-B MTH1100-072010 16.2 Page...
Page 25
MTH-1100 ASSEMBLY INSTRUCTIONS 9542-145-line link AK 9542-148-line link 9545-034 Above shows STEP 9 assembled and completed Figure 4 9542-145-Line 9542-148-Line M4X12L ROUND ALLEN CROSS BOLT X2 LINK AA LINK D22 LINK AA M4X12L ROUND ALLEN CROSS BOLT X4 M6X12L ROUND BOLT X5 M6 WASHER Ø14X4 M6 WASHER Ø14X5 M6X12L ROUND BOLT X4...
Page 26
MTH-1100 ASSEMBLY INSTRUCTIONS M10X12L ROUND BOLT X4 Above shows STEP 10 assembled and completed EXTRUDING EXTRUDING Figure 5 Note: When installing the shroud (AD), push both sides of the shroud toward center in order to bend it a little. After insert it to the door frame and then releasing it. The shroud will be locked on the door frame.
