Summary of Contents for Eneo AK-29

  • Page 1 Quick Installation Guide AK-29 Accessory part for eneo products Learn more about eneo IN series on our YouTube channel.
  • Page 3: Table Of Contents

    TABLE OF CONTENT SAFETY INSTRUCTIONS ....................... 4 General ......................................4 Dimensions (in mm) & Specifications ..........................7 Parts supplied ................................... 7 INSTALLATION ........................8 Ceiling Mount ................................... 8 Wall Mount ....................................9...
  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS General • Before switching on and operating the system, first read this safety advice and the operating instructions. • Keep the operating instructions in a safe place for later use. • Installation, commissioning and maintenance of the system may only be carried out by authorised individuals and in accordance with the installation instructions - ensuring that all applicable standards and guidelines are followed.
  • Page 6 WEEE (Waste Electronical & Electronic Equipment) Correct Disposal of This Product (Applicable in the European Union and other European countries with separate collection systems). This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
  • Page 7: Dimensions (In Mm) & Specifications

    PRIOR TO USE • Install the mount onto a strong structure such as concrete wall • Use the supplied accessories when installing the mount bracket depends on mounting position Dimensions (in mm) & Specifications Construction: Aluminum Cast Dimensions(mm): Ø 150,00 x 68,60 Weight: 511,00 g (1.13 lb) Parts supplied...
  • Page 8: Installation

    3. Feed the power and BNC cable through the tube. 4. Fix the tube to the ceiling with four screws. 5. Screw the box (AK-29) into the other end of the tube, then tighten the screws on the side of the tube.
  • Page 9: Wall Mount

    Wall Mount In combination with Dome-WB6 The detailed work steps are comparable to those for ceiling installation. Follow the steps described on the previous page.
  • Page 11 INHALTSVERZEICHNIS SICHERHEITSHINWEISE .......................12 Allgemein ....................................12 Abmessungen (in mm) & Spezifikationen ........................15 Lieferumfang ................................... 15 INSTALLATION ........................16 Deckenmontage ..................................16 Wandmontage ..................................17...
  • Page 12: Sicherheitshinweise

    SICHERHEITSHINWEISE Allgemein • Bevor Sie das System anschließen und in Betrieb nehmen, lesen Sie zuerst diese Sicherheitshinweise und die Betriebsanleitung. • Bewahren Sie die Betriebsanleitung sorgfältig zur späteren Verwendung auf. • Montage, Inbetriebnahme und Wartung des Systems darf nur durch dafür autorisierte Personen vorgenom- men und entsprechend den Installationsanweisungen - unter Beachtung aller mitgeltenden Normen und Richtlinien - durchgeführt werden.
  • Page 14 WEEE-Richtlinie (Elektro- und Elektronik-Altgeräte) Ordnungsgemäße Entsorgung dieses Produkts (Gilt für die Europäische Union und die anderen Europäischen Länder mit getrennten Sammelsystemen) Dieses am Produkt oder in seiner Dokumentation gezeigte Symbol bedeutet, dass es am Ende seiner Lebensdauer nicht mit dem Hausmüll entsorgt werden darf. Um eventuelle Umwelt- oder Gesund- heitsschäden durch unkontrollierte Abfallbeseitigung zu verhindern, dieses Gerät von anderen Ab- fallarten trennen und ordnungsgemäß...
  • Page 15: Abmessungen (In Mm) & Spezifikationen

    VOR DEM GEBRAUCH • Die Anschlussbox an einer tragfähigen Struktur wie z. B. einer Betonwand befestigen. • Verwenden Sie bei der Montage der Halterung je nach Montageposition das mitgelief- erte Zubehör Abmessungen (in mm) & Spezifikationen Ausführung: Aluminiumguss Abmessungen(mm): Ø 150,00 x 68,60 Gewicht: 511,00 g Lieferumfang...
  • Page 16: Installation

    3. Führen Sie das Strom- und BNC-Kabel durch das Rohr 4. Befestigen Sie das Rohr mit vier Schrauben an der Decke. 5. Schrauben Sie die Box (AK-29) in das andere Ende des Rohrs, und ziehen Sie dann die Schrauben des Rohrs an der Seite fest.
  • Page 17: Wandmontage

    Wandmontage In Kombination mit Dome-WB6 Die detaillierten Arbeitsschritte sind vergleichbar mit denen der Deckenmontage. Befolgen Sie die auf der vorherigen Seite beschriebenen Arbeitsschritte.
  • Page 20 Videor E. Hartig GmbH Exclusive distribution through specialised trade channels only. Videor E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark / Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
