PRIOR to USE
Install the mount onto a strong structure such as concrete wall
Use the supplied accessories when installing the mount bracket depends on mounting position
DIMENSION
(Unit: mm)
PARTS SUPPLIED
Dual Junction Box
Water proof Stopper
6 x Screws
AK24 Quick Installation Guide (EN)
Screw Driver
6 x Screws
Stopper For Wire
SPECIFICATION
Construction: Aluminum Cast
Environment: Ceiling mount for a Bullet
Dimension(mm): 310x156x70 mm
Weight: 1165g (2.57lb)
4 x Screws
Installation Template
4 x Expansion Bolt
QIG
Advertisement
Related Manuals for Eneo AK24
Summary of Contents for Eneo AK24
- Page 1 AK24 Quick Installation Guide (EN) PRIOR to USE Install the mount onto a strong structure such as concrete wall Use the supplied accessories when installing the mount bracket depends on mounting position DIMENSION SPECIFICATION (Unit: mm) Construction: Aluminum Cast Environment: Ceiling mount for a Bullet Dimension(mm): 310x156x70 mm Weight: 1165g (2.57lb)
-
Page 2: Installation
AK24 Quick Installation Guide (EN) INSTALLATION WALL MOUNT 1. Locate the mounting template at the installation position and drill the wall. 2. Remove the release paper of bracket pad and attach to rear plate of the bracket 3. Route the power and BNC cable through the bracket 4. - Page 3 AK24 Quick Installation Guide (EN)
- Page 4 AK24 Quick Installation Guide (EN) 2. Allow you match the bracket WB-24 + CM22 for Corner mount.
- Page 5 AK24 Quick Installation Guide (EN) 3. Also allow you directly install the Junction box to the wall or ceiling. Details please refer to the below Figures. You can match Dome and/or bullet camera with the Junction Box, the operation steps are same as above-mentioned bracket-wall mount.
