AK-26 Quick Installation Guide (EN) PRIOR to USE Install the mount onto a strong structure such as concrete wall Use the supplied accessories when installing the mount bracket depends on mounting position DIMENSION SPECIFICATION (Unit: mm) Construction: Aluminum Cast Environment: Ceiling mount for a Bullet Dimension (mm): 146.7x62.0mm...
AK-26 Quick Installation Guide (EN) INSTALLATION Ceiling Mount 1. Locate at the installation position and drill the wall. 2. Hammer the 4 expansion screws into the wall holes drilled 3. Route the power and BNC cable through the Pipe 4.
AK-26 Quick Installation Guide (EN) Wall Mount Allow the Junction Box match with the Bracket (DOME-WB6) for the Wall Mount. Detailed operation steps are similar with the Ceiling Mount. Please refer to.
Page 4
AK-26 Quick Installation Guide (EN) Pillar Mount Allow the Junction Box match with the Bracket (DOME-WB6) +Pillar Bracket (PM-21) to mount the camera on one Pole. 1. Fix the Pillar Bracket on one Pole through two Hoops to control tightness 2.
AK-26 Quick Installation Guide (EN) Corner Mount Allow the Junction Box match with the Bracket (DOME-WB6) + Corner Bracket (CM22) for the Corner Mount. Detailed operation steps are similar with the Pillar Mount. Please refer to.
