Eneo 235526 Quick Installation Manual

PRIOR to USE

Install the mount onto a strong structure such as concrete wall

Use the supplied accessories when installing the mount bracket depends on mounting position

(Unit: mm)

Junction Box

4 x Expansion Bolt

AK-26 Quick Installation Guide (EN)

Waterproof Stopper

Construction: Aluminum Cast

Environment: Ceiling mount for a Bullet

Dimension(mm): 146.7x46.2mm

Weight: 248g (0.55 lb)

Stopper for Wire

QIG

Rubber

Screws, Water-proof

Table of Contents

Do you have a question about the 235526 and is the answer not in the manual?

Page 1 AK-26 Quick Installation Guide (EN) PRIOR to USE Install the mount onto a strong structure such as concrete wall Use the supplied accessories when installing the mount bracket depends on mounting position DIMENSION SPECIFICATION (Unit: mm) Construction: Aluminum Cast Environment: Ceiling mount for a Bullet Dimension(mm): 146.7x46.2mm Weight: 248g (0.55 lb) PARTS SUPPLIED...
Page 2 AK-26 Quick Installation Guide (EN) INSTALLATION  CEILING MOUNT 1. Locate the mounting template at the installation position and drill the wall. 2. Hammer the 4 expansion screws into the wall holes drilled 3. Route the power and BNC cable through the Box 4.
