Always Moving For ward
Owner's Manual
Sp8
Indoor Cycle

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sp8 and is the answer not in the manual?

Questions and answers

Summary of Contents for CIRCLE FITNESS Sp8

  • Page 1 Always Moving For ward Owner’s Manual Indoor Cycle...
  • Page 3 F1654001-01 SP8_11012 ATTENTION: Read instructions carefully, failure to do so may cause permanent damage to your bike. Please verify that all parts associated with this product are in good condition and accounted for. During the assembly process please be sure to follow each step accordingly as it has been explained within the manual.
  • Page 4: Safety Information

    SAFETY INFORMATION: 1. Keep children and pets away from this equipment at all times. DO NOT leave them unsupervised in the room where the machine is kept. 2. If you experience dizziness, nausea, chest pains or any other symptom while using this machine STOP the exercise.
  • Page 5 CAUTION: During assembly it is recommended that all bolts be tightened by hand, upon completing assembly, bolts should then be properly secured using the wrench provided. To avoid injury, check bolts carefully before use. Assembly Step one Attach the front foot tube (18) first by lifting up the front of the frame and sliding the front foot tub under the frame.
  • Page 6 Step three Insert the seat post (43) into the seat tube on the frame. Attach the saddle (1) into seat slider (42). Then tighten seat clamp’s nut. Insert the seat slider (42) into the seat post (43) and fix. Loose the release lever (6) to adjust the height and distance in the desired position, and tighten it finally.
  • Page 7: Right Pedal

    Right Pedal Please make sure pedal in your hand is the right pedal before Installation. Please refer to the figure. Align the right pedal with right crank at 90 degree. Gently insert the pedal in the crank arm. Turn the pedals clockwise as tightly as you can with your hand. Use the wrench to ensure it is tightened securely.
  • Page 8 Adjusting the resistance Adjust the exercise resistance on the spinning bike using the tension knob (24) to loosen (-) or tighten (+). Stability If the floor is not even, you can adjust the height by foot tube adjuster pad (13) to make it firmly.
  • Page 9: Exploded Drawing

    Exploded Drawing...
  • Page 10: Part List

    Part list Name Unit No. Name Unit Saddle Flywheel axle Alloy bind clamp ( L ) Fixed wheel nut Spring for release lever Flywheel bearing 15,15-1 Alloy bind clamp ( R ) Flywheel security washer & nut 15-2 Washer for release lever Rubber cover for flywheel Release lever Axle bolt for moving wheel...
  • Page 11 Instruction It is important that the handlebar and seat are set at the correct height for your body. Ask your instructor for assistance. Adjusting the handlebar height-Undo Handlebar adjustment - the adjuster release lever that is located at head tube (where the handlebar post fits into the frame).
  • Page 12: Maintenance Chart

    Maintenance Chart DESCRIPTION Daily Weekly Monthly Quarterly Annually Keep machine clean: Wipe machine down with clean & dry fabric to clear dirt & sweat. Wipe Anti-rusty cream or similar on the seat post set, handlebar set Visual check Check security of handle bar post & seat post Check security of saddle Remove handlebar post and clean...
  • Page 13: Computer Instructions

    Computer Instructions DISPLAY FUNCTION: ITEM DESCRIPTION . In SCAN mode, press MODE/ENTER key to choose functions. . Automatically scan through each mode in sequence every 6 seconds. SCAN . The sequence of display when press MODE/ENTER key : TIME→ DIST→CAL→PULSE/LOAD→RPM/SPEED .
  • Page 14 KEY FUNCTION: ITEM DESCRIPTION . Press SET key to increase value. Press and hold the key to increase value faster. . TIME setting range: 00:00~99:00 (Each increment is 1:00) . CAL setting range: 0~9990 (Each increment is 10) . DIST setting range: 0.00~99.50 (Each increment is 0.5) .
  • Page 15: Operation

    OPERATION Workout setting Press MODE/ENTER key to select the function of TIME, DISTANCE,CALORIES and PULSE.  Use SET Key for setting and press MODE key for confirmation. For instance the time set-up, when the time value is blinking, you can use SET Key to adjust the ...
  • Page 16 Always Moving For ward Sp8 Indoor Cycle www.circlefitness.com...
